尼龙快拆式旋转阀密封优越，用感无忧：结构稳定，密封性能良好。可用于粉料、小颗粒物料，在正负极压差吸送过程中将物料分离排出。采用加厚叶轮设计，与壳体配合间隙小，结构精密，使用过程中不易漏风不易漏料，防堵耐用。

　　此产品由本公司自主研制，适用于不可接触金属物料的卸料。箱体、叶轮以及端盖，都采用整块尼龙铣削加工，结构牢靠，运行无噪音，相较于陶瓷阀，可以节省成本，是锂电行业新宠。【电话/微信咨询：陈经理18068546632】

　　快速清洗型：快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。

　　可拆卸叶轮：便于快速拆卸清洗旋转阀的物料接触面。

　　驱动方式：链驱动/马达直连驱动。

　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)。

　　材质：尼龙系列。

　　滑杆式：清洗前的拆卸。松开螺栓手柄，沿导柱将端盖轻轻拉至极限，抽出叶轮，双手握住叶轮两端抽颈取出。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。【电话/微信咨询：陈经理18068546632】

　　快开门式：操作方法基本如上所述。

            《扫二维码-添加 陈经理 微信-咨询产品或定制》

　　Nylon quick release rotary valve has superior sealing and worry free use: stable structure and good sealing performance. Can be used for powder and small particle materials, to separate and discharge materials during the positive and negative pressure difference suction process. Adopting a thickened impeller design, the clearance between the impeller and the shell is small, the structure is precise, and it is not easy to leak air or materials during use, and it is durable and anti clogging.

　　This product is independently developed by our company and is suitable for unloading non-contact metal materials. The casing, impeller, and end cover are all processed using a single piece of nylon milling, with a reliable structure and noiseless operation. Compared to ceramic valves, they can save costs and are a new favorite in the lithium battery industry.

　　Rapid cleaning type: the rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.

　　Detachable impeller: facilitates quick disassembly and cleaning of the material contact surface of the rotary valve.

　　Drive mode: chain drive/motor direct connection drive.

　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).

　　Material: Nylon series.

　　Sliding rod type: disassembly before cleaning. Release the bolt handle, gently pull the end cover along the guide pillar to the limit, extract the impeller, and hold both ends of the impeller with both hands to extract the necks. After cleaning, install the impeller (rotate the impeller to fit the spline teeth), push in the end cover (rotate the movable shaft handle to fit the spline teeth), and tighten the bolt handle.

　　Quick opening type: The operation method is basically as described above.
