【粘料专用】刮板式自清理星型卸料器DN300/ 自清洁卸料阀,刮板自清理关风机,自清理关风器
产品介绍刮板式自清理星型卸料器,设有进出料口的阀体,叶轮片和叶轮轴,所述的叶轮片铰接在叶轮轴上;所述的叶轮轴的两端通过轴承座架设置在阀体的内部,其中,叶轮轴的一端与减速电机相连,另一端设有第一齿轮;在所述的阀体的下部设有用于清理清洁叶轮片的刮板,刮板与第二齿轮相连,所述的第一齿轮与第二齿轮啮合.新型的自清理清洁式星型卸料器不仅能有效清理叶轮片上的黏粘性物料,保证物料输送的顺利进行,而且充分利用叶轮轴转动来驱动物料的清除动作,节省了能源的同时降低了生产成本;同时该设备结构简单,易于保养和维护,具有很好的实用性。 什么样的物料用刮板式自清理星型卸料器? 1、静电吸附性粉粒物料:如某些化工粉末、塑料粉末,因静电吸附在转子叶片上,普通旋转阀难以靠重力卸净。 2、粘性、易吸湿结块的粉粒体:包括需防潮防堵的精细化工、食品原料等。 3、吸湿粘性物料:如煤粉、水泥、污水污泥,易吸收空气中的水分,粘附在设备内壁。 4、易结块、架桥物料:在料仓或阀体内易搭成“拱桥”,导致卸料不畅,刮板式结构可边输送边清理,防止架桥。 工作原理: 刮板式自清理卸料阀的核心是在普通旋转阀基础上,增加一套与阀芯同步转动的刮板清理机构,在卸料的同时自动刮除粘附在转子槽壁上的物料。 常见应用行业: 钢厂、电厂、水泥、矿山:原料输送中粉煤灰、水泥粉、矿粉等易吸湿结块物料。 化工、环保、塑料、粮食医药:粉体输送、卸料、计量环节,处理易粘附、易架桥的粉粒混合物。 尺寸:DN100 ~ DN2000.方口100*100 ~ 5000*4000.或非标定制。 材质:304~316.Q235.Q355.耐磨400.耐磨500.高锰钢(ZG120Mn18Cr2/Mn13),耐磨合金,陶瓷等。 电机、减速机:皖南、卧龙、国茂、西门子、ABB、SEW、Flender、NORD、住友、防爆型可选,或客户指定品牌。 部分客户需求: 物料:脱硫石膏等有粘性粉状湿料,物料水分:≤20 %;使用环境-30°C~60°,输送量6t~8t/h,材质S30408.尺寸DN300.变频调速,所有电气、仪表设施均需考虑气体和粉尘复合防爆,防爆等级为ExdⅡBT4 Gb&ExtD IIIC T120℃Db IP65.电机能效等级不低于二级。 物料:聚合物颗粒,固体含水率:6%~8%;物料粒径<3mm,含微量细粉;物料堆密度:0.83g/mL;物料温度:≤40℃,输送量3200kg/h,尺寸DN300.刮板式自清洁星型下料阀采用S30408材质,内表面抛光Ra≤0.4um;旋转下料阀法兰连接,压力等级PN10.密封铭型式RF;轴端密封采用迷宫气密封,配套过滤调压气源组件;旋转阀配套卡料警报装置;旋转下料阀电机变频;电机气体/粉尘防爆,防爆等级Exdb IIBT4 GbEx /tb IIIC T130℃ Db;旋转下料阀漏气量设计尽可能小;轴承型式为外置双轴承;旋转下料阀阀体采用一体铸造式。 自清洁功能的关风机,物料是有一定湿度的柠檬酸镁,有粘性。含水率大概30%左右,离心机出料后的柠檬酸镁物料,输送量3t~4t/h,尺寸DN300.材质不锈钢,一线品牌减速机及电机。 出口海外星型卸料器,自清洁及易清洁,食品产品,工作温度 80℃,产能 2t/h,产品密度为0.5吨/立方米,设备上方压力为 0.4bar,设备下方压力为 0bar(机械运输),含水量约10%,中等粘性,卸料器材质不锈钢316L。 物料:干湿混合的石膏,有一定粘性,湿料,输送量5t/h,随后落到风干机,材质碳钢,自清理卸料器起到一个卸料和锁风效果,锁风不需要太严,主要解决粘连附在转子上。 我公司常州同得利/江苏同得利专业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、YJD型旋转阀,快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。 《扫二维码-添加 陈经理 微信-咨询刮板式自清理卸料器设备》 Scraper type self-cleaning star shaped unloader, equipped with a valve body for inlet and outlet, impeller blades, and impeller shaft, wherein the impeller blades are hinged on the impeller shaft; The two ends of the impeller shaft are set inside the valve body through bearing seats, wherein one end of the impeller shaft is connected to the reduction motor, and the other end is provided with a first gear; A scraper for cleaning the impeller blades is provided at the lower part of the valve body, and the scraper is connected to the second gear. The first gear meshes with the second gear The new self-cleaning star shaped unloader not only effectively cleans the viscous materials on the impeller blades, ensuring smooth material transportation, but also fully utilizes the rotation of the impeller shaft to drive the material removal action, saving energy and reducing production costs; At the same time, the device has a simple structure, is easy to maintain and upkeep, and has good practicality. What kind of material is used with a scraper self-cleaning star shaped unloader? 1. Electrostatic adsorption granular materials, such as certain chemical powders and plastic powders, are difficult to discharge by gravity due to electrostatic adsorption on the rotor blades of ordinary rotary valves. 2. Viscous and hygroscopic powder particles: including fine chemical and food raw materials that require moisture and blockage prevention. 3. Moisture absorbing and viscous materials, such as coal powder, cement, and sewage sludge, are prone to absorbing moisture from the air and adhere to the inner walls of equipment. 4. Materials that are prone to clumping and bridging: They can easily form an "arch bridge" in the silo or valve body, causing poor unloading. The scraper structure can be used to clean while conveying to prevent bridging. Working Principle: The core of the scraper type self-cleaning discharge valve is to add a scraper cleaning mechanism that rotates synchronously with the valve core on the basis of a regular rotary valve, automatically scraping off the material adhered to the rotor groove wall while discharging. Common application industries: Steel mills, power plants, cement, and mines: materials such as fly ash, cement powder, and mineral powder that are prone to moisture absorption and agglomeration during raw material transportation. Chemical, environmental protection, plastics, grain and medicine: powder conveying, unloading, and metering processes, handling powder particle mixtures that are prone to adhesion and bridging. Size: DN100~DN2000. square mouth 100 * 100~5000 * 4000. or non-standard customization. Material: 304~316. Q235.Q355. Wear resistant 400. wear resistant 500. high manganese steel (ZG120Mn18Cr2/Mn13), wear-resistant alloy, ceramics, etc. Motors and reducers: Wannan, Wolong, Guomao, Siemens ABB、SEW、Flender、NORD、 Sumitomo, explosion-proof type optional, or customer specified brand. Partial customer requirements: Material: Viscous powdery wet materials such as desulfurization gypsum, with a moisture content of ≤ 20%; The operating environment is -30 ° C~60 ° C, with a conveying capacity of 6t~8t/h. The material is S30408. the size is DN300. and the variable frequency speed regulation is required. All electrical and instrumentation facilities need to consider gas and dust composite explosion-proof, with an explosion-proof level of Exd Ⅱ BT4 Gb&ExtD IIIC T120 ℃ Db IP65. and the motor energy efficiency level is not lower than level two. Material: Polymer particles, solid moisture content: 6% to 8%; Material particle size<3mm, containing trace amounts of fine powder; Material bulk density: 0.83g/mL; Material temperature: ≤ 40 ℃, conveying capacity 3200kg/h, size DN300. The scraper type self-cleaning star shaped discharge valve is made of S30408 material, with a polished inner surface Ra ≤ 0.4um; Rotary discharge valve flange connection, pressure rating PN10. sealing type RF; shaft end seal adopts labyrinth gas seal, matched with filter pressure regulating gas source component; Rotary valve matching card alarm device; Rotating feeding valve motor frequency conversion; Motor gas/dust explosion-proof, explosion-proof grade Exdb IIBT4 GbEx/tb IIIC T130 ℃ Db; the design of the rotary feeding valve should minimize the leakage rate as much as possible; The bearing type is external double bearing; The rotary discharge valve body adopts an integral casting type. The self-cleaning function of the shutdown fan is made of magnesium citrate with a certain humidity and viscosity. The moisture content is about 30%. The magnesium citrate material discharged from the centrifuge has a conveying capacity of 3t~4t/h, a size of DN300. made of stainless steel, and equipped with a first-line brand reducer and motor. Export overseas star shaped unloader, self-cleaning and easy to clean, food product, working temperature of 80 ℃, production capacity of 2t/h, product density of 0.5 tons/cubic meter, pressure above the equipment of 0.4 bar, pressure below the equipment of 0 bar (mechanical transportation), moisture content of about 10%, medium viscosity, unloader material made of stainless steel 316L. Material: Gypsum mixed with dry and wet materials, with a certain viscosity. The wet material has a conveying capacity of 5t/h and then falls into the air dryer. The material is carbon steel, and the self-cleaning unloader plays a role in unloading and air locking. The air locking does not need to be too strict, mainly to solve the adhesion to the rotor. Our company Changzhou Tongdeli/Jiangsu Tongdeli specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, YJD type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high temperature and high pressure rotary valves, high temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE PTFE nylon polyurethane, arch breaking machines, silo scraper crushers, breaking valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.查看详情 +
-
刮板式自清洁卸料阀GBS-E-450x300/ 自清洁卸料器,自清理旋转卸料阀,刮板式卸料器
产品介绍刮板式自清洁旋转卸料阀:物料参数:竹木粉加工,水分含量8%~10%,堆比重40kg/m³;卸料量:6500kg/h。使用温度:≤120℃。使用压力:正压,2kpa至6kpa。卧龙电机:变频电机,防爆,防护等级IP55.材质:不锈钢SUS304.有良好的密封性。 刮板式自清洁卸料阀: 刮板式自清洁卸料阀,它涉及锂电、钢厂、电厂、水泥、矿山、竹木粉加工等技术领域。它包括电机、壳体、弧形叶轮和旋转刮板,弧形叶轮安装在壳体内部,弧形叶轮通过电机驱动;旋转刮板设置在弧形叶轮的下方,旋转刮板的顶部与弧形叶轮的弧面相接触,旋转刮板与弧形叶轮之间通过壳体外的齿轮传动机构进行同步反向转动。本实用新型设计合理,节约能耗,利用弧形叶轮与旋转刮板的配合实时对叶轮进行自清洁,以杜绝叶轮间残留粉料。 刮板式旋转阀的核心原理,是在普通旋转阀的基础上,增加一套与阀芯联动的刮板清理机构,在旋转卸料的同时,把粘附在转子料斗(承料槽)内壁上的物料实时刮除。 阀体上开有清理口便于定期清除内部的物料,设备带扭力保护器。 尺寸:DN100 ~ DN2000.方口100*100 ~ 5000*4000.或非标定制。 材质:304~316.Q235.Q355.耐磨400.耐磨500.高锰钢(ZG120Mn18Cr2/Mn13),耐磨合金,陶瓷等。 电机、减速机:皖南、卧龙、国茂、西门子、ABB、SEW、Flender、NORD、住友、防爆型可选,或客户指定品牌。 部分行业常见粘性物料: 制药与精细化工行业:API粉体、辅料等,不仅粘性强,还对卫生和清洁度要求高。 化工与橡胶行业:化工粉料、碳黑、钛白粉、聚合物颗粒等,易吸潮结块或粘附设备壁面。 煤炭与矿山行业:煤炭末、煤泥、矿粉等湿粘性物料,筛分、输送、仓储环节易堵孔、结拱。 建材与水泥行业:水泥生料、粉煤灰、矿渣粉、砂石分级中的湿料,仓内易结拱、粘仓壁。 粮食与食品行业:粮食颗粒、面粉、淀粉、糖粉等,含湿或含油时粘性显著增强。 常州同得利机械厂/江苏同得利科技专业的团队,拥有二十余年经验,定制、设计、研发、生产经验丰富。为您提供专业的设计、选材和指导,为不同使用工况量身打造一体化的输送设备。自动精加工中心,搭配进口自动设备,专有生产工装,提高生产效率和精度。 《扫二维码-添加 陈经理 微信-咨询刮板式自清洁卸料阀》 Scraper type self-cleaning rotary discharge valve: Material parameters: bamboo and wood powder processing, moisture content of 8%~10%, bulk density of 40kg/m ³; Unloading capacity: 6500kg/h. Operating temperature: ≤ 120 ℃. Use pressure: positive pressure, 2kpa to 6kPa. Wolong Motor: Variable frequency motor, explosion-proof, protection level IP55. Material: Stainless steel SUS304. with good sealing performance. Scraper type self-cleaning discharge valve: Scraper type self-cleaning discharge valve, which involves technical fields such as lithium batteries, steel mills, power plants, cement, mining, bamboo and wood powder processing, etc. It includes a motor, a housing, an arc-shaped impeller, and a rotating scraper. The arc-shaped impeller is installed inside the housing and is driven by a motor; The rotating scraper is set below the arc-shaped impeller, and the top of the rotating scraper is in contact with the arc-shaped surface of the impeller. The rotating scraper and the arc-shaped impeller rotate synchronously in reverse through a gear transmission mechanism outside the shell. This utility model has a reasonable design, saves energy consumption, and uses the combination of curved impellers and rotating scrapers to perform real-time self-cleaning of the impellers to eliminate residual powder between them. The core principle of the scraper rotary valve is to add a scraper cleaning mechanism that is linked to the valve core on the basis of a regular rotary valve. While rotating and unloading, the material adhered to the inner wall of the rotor hopper (receiving groove) is scraped off in real time. There is a cleaning port on the valve body for regular removal of internal materials, and the equipment is equipped with a torque protector. Size: DN100~DN2000. square mouth 100 * 100~5000 * 4000. or non-standard customization. Material: 304~316. Q235.Q355. Wear resistant 400. wear resistant 500. high manganese steel (ZG120Mn18Cr2/Mn13), wear-resistant alloy, ceramics, etc. Motors and reducers: Wannan, Wolong, Guomao, Siemens ABB、SEW、Flender、NORD、 Sumitomo, explosion-proof type optional, or customer specified brand. Common viscous materials in some industries: The pharmaceutical and fine chemical industry: API powders, excipients, etc. not only have strong viscosity, but also require high hygiene and cleanliness. Chemical and rubber industry: Chemical powders, carbon black, titanium dioxide, polymer particles, etc. are prone to moisture absorption, agglomeration, or adhesion to equipment walls. Coal and mining industry: Wet and viscous materials such as coal fines, coal slurry, and mineral powder are prone to clogging and arching during screening, transportation, and storage processes. Building materials and cement industry: Wet materials in cement raw materials, fly ash, slag powder, and sand and gravel grading, which are prone to arching and sticking to warehouse walls. Grain and food industry: Grain granules, flour, starch, sugar powder, etc. have significantly increased viscosity when wet or oily. Changzhou Tongdeli Machinery Factory/Jiangsu Tongdeli Technology has a professional team with over 20 years of experience in customization, design, research and development, and production. We provide professional design, material selection, and guidance to tailor integrated conveying equipment for different operating conditions. Automatic precision machining center, equipped with imported automatic equipment and proprietary production fixtures, improves production efficiency and accuracy.查看详情 +
-
(BGB)刮板式旋转卸料阀-替代日本品牌/ 自清洁旋转阀,自清理旋转卸料阀,刮板式旋转阀
产品介绍刮板式旋转卸料阀,自清洁粘性物料,之前客户用的配套设备日本进口品牌,目前磨损及损坏,需替代更换,尺寸700*500.布袋除尘器卸料阀:用途:用于尾气中通过布袋除尘器分离的物料卸料。物料参数:含有少量的玉米秸秆叶片、泥土、秸秆碎屑,水分含量6-10%,堆比重30kg/m³;单台卸料量,3500kg/h。使用温度:≤120℃。使用压力:负压,-3kpa至-8kpa。电机:工频,防爆,SEW。材质:耐磨合金钢,有良好的密封性。 刮板式旋转阀,包括阀体,阀体内设置有阀芯腔;阀芯,转动设置于阀芯腔内,阀芯上开设有若干用于承接物料的承料槽;清理机构,设置于阀体的出料端,位于阀芯下方,清理机构可绕自身轴线转动对残留于承料槽内壁处的物料进行清理刮除;驱动机构,与阀芯传动连接,用于驱动阀芯转动;传动机构,连接阀芯与清理机构.本发明通过设置与阀芯同步转动的清理机构,在阀芯工作过程中,刮板实时对承料槽进行刮擦,可有效清除粘附在槽壁上的物料,特别是针对粘性,易吸湿结块的物料,能显著防止物料架桥和积料,大幅降低了人工清洁的频率和停机时间,提高了生产连续性. 刮板式旋转阀与普通旋转阀的区别: 普通旋转阀的转子叶片与壳体配合形成密封腔,靠物料重力卸料,但对粘性、易结块物料易残留堵塞。刮板式旋转阀增加刮板机构,卸料同时完成自清洁,大幅降低人工清洁频率和停机时间,提高生产连续性。 尺寸:DN100 ~ DN2000.方口100*100 ~ 5000*4000.或非标定制。 材质:304~316.Q235.Q355.耐磨400.耐磨500.高锰钢(ZG120Mn18Cr2/Mn13),耐磨合金,陶瓷等。 电机、减速机:皖南、卧龙、国茂、西门子、ABB、SEW、Flender、NORD、住友、防爆型可选,或客户指定品牌。 我们购买旋转卸料阀输送物料时,如何才能选择合适的厂家? 选择实力强的厂家,一般来说旋转卸料阀厂家可以见证产品的质量,实力强的厂家可为客户提供更好的产品质量和服务。 要看厂家的实力、信誉、规模。 我公司常州同得利/江苏同得利专业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、YJD型旋转阀,快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。 Scraper rotary discharge valve, self-cleaning viscous material, previously used by the customer as a matching equipment from a Japanese imported brand, currently worn and damaged, needs to be replaced, size 700 * 500. Bag filter discharge valve: Used for discharging materials separated by bag filter in exhaust gas. Material parameters: Contains a small amount of corn straw leaves, soil, and straw debris, with a moisture content of 6-10% and a bulk density of 30kg/m ³; Single unloading capacity, 3500kg/h. Operating temperature: ≤ 120 ℃. Use pressure: negative pressure, -3kpa to -8kpa. Motor: power frequency, explosion-proof, SEW。 Material: Wear resistant alloy steel with good sealing properties. Scraper type rotary valve, including a valve body, with a valve core chamber set inside the valve body; The valve core is set to rotate inside the valve core chamber, and there are several material receiving grooves on the valve core for receiving materials; A cleaning mechanism is installed at the discharge end of the valve body, located below the valve core. The cleaning mechanism can rotate around its own axis to clean and scrape off the material remaining on the inner wall of the material receiving groove; Drive mechanism, connected to the valve core for transmission, used to drive the valve core to rotate; Transmission mechanism, connecting valve core and cleaning mechanism The present invention sets up a cleaning mechanism that rotates synchronously with the valve core. During the operation of the valve core, the scraper real-time scrapes the material receiving groove, which can effectively remove the materials adhered to the groove wall, especially for viscous and hygroscopic materials. It can significantly prevent material bridging and accumulation, greatly reduce the frequency and downtime of manual cleaning, and improve production continuity. The difference between scraper rotary valve and ordinary rotary valve: The rotor blades of a regular rotary valve cooperate with the housing to form a sealed chamber, which is discharged by the gravity of the material, but it is prone to residual blockage of viscous and easily clumped materials. The scraper type rotary valve adds a scraper mechanism, which completes self-cleaning while unloading, significantly reducing manual cleaning frequency and downtime, and improving production continuity. Size: DN100~DN2000. square mouth 100 * 100~5000 * 4000. or non-standard customization. Material: 304~316. Q235.Q355. Wear resistant 400. wear resistant 500. high manganese steel (ZG120Mn18Cr2/Mn13), wear-resistant alloy, ceramics, etc. Motors and reducers: Wannan, Wolong, Guomao, Siemens ABB、SEW、Flender、NORD、 Sumitomo, explosion-proof type optional, or customer specified brand. How can we choose a suitable manufacturer when purchasing a rotary discharge valve to transport materials? Choosing a manufacturer with strong capabilities, generally speaking, a rotary discharge valve manufacturer can witness the quality of the product, and a strong manufacturer can provide customers with better product quality and service. It depends on the strength, reputation, and scale of the manufacturer. Our company Changzhou Tongdeli/Jiangsu Tongdeli specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, YJD type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high temperature and high pressure rotary valves, high temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE PTFE nylon polyurethane, arch breaking machines, silo scraper crushers, breaking valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.查看详情 +
-
