进口品牌德国科贝隆Coperio**，zeppeli**泽普琳、荷兰DMN、格律克Gericke、威埃姆WAMGROUP、芬兰BMH、美国派力特隆pelletron旋转阀 。常州同得利专注研发生产高端旋转阀，拥有多年的研发生产/定制非标旋转阀卸料阀的经验，口碑好，旋转阀性能优越，让物料更流畅，使用更精久。　　国产选大品牌-国盛商标常州同得利，专 利技术，匠心质造。工匠精神是中国的瑰宝，它是我们民族文化的结晶，更是中华民族的灵魂所在。【电话/微信咨询：陈经理18068546632】　　滑杆式旋转阀/星型卸料阀/关风机卸料器/旋转供料器主要结构：外壳金属；物料接触部分：内衬陶瓷、陶瓷氧化铝、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢。　　尺寸：DN50~~非标定制。　　清洗型滑杆式旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于锂电、化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。本产品对标全球一线品牌的旋转阀，性能更优，价格&交期更好!　　清洗型旋转阀特点：物料粘接设备，可以快速清理，快速复位。稳定性优于其他开拆式阀门，可原地抽出转子。清洗前的拆卸：松开活动端盖上的螺旋手柄，沿柱将端盖和转子一起拉出，松开轴端的螺旋手柄，取出转子。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。【电话/微信咨询代替方案：陈经理18068546632】　　滑杆式旋转阀主要用于输送锂电池正极材料、磷酸铁锂、三元材料、化工粉料/颗粒、食品、塑料等。　　同得利秉承以下服务承诺:　　服务目标：服务质量赢得用户满意。　　严格控制对产品性能的检测，待产品被确认合格后再出厂发货。　　提供的产品符合报价文件承诺和所签合同规定的技术要求。　　物美价廉，具有输送系统完全密闭，可以避免输送物料的受潮、污损或混入异物等优势，常用于锂电/化工/药材/食品/塑料/钢厂/电厂/矿山/水泥/环保等行业。　　全新的铸造方法用于改善外表面光洁度和铸造完整性，阀体外壳强度更高。【电话/微信咨询：陈经理18068546632】　　我公司是集科研、开发、设计、制造、售后服务于一体的环保型机械重 点企业。公司地处经济发达的长江金三角，坐落在全国闻名的科技示范城-龙城常州，地理位置优越，千年古运河入境而过，沿江高速、京沪高速、沪宁高速纵横交错，交通十分便利。　　公司在强化企业管理的基础上，依靠科技进步提高技术含量，先进的生产加工设备，领 先的管理理念，高素质的员工团队，有效的质量保障体系和完善的售后服务，为制造高品质的产品提供可靠的保证，极大的满足了各行业的需求，深受广大客户的信赖。　　我公司始终坚持“质量第 一、用户至 上”的宗旨，服务于社会，诚信于业界，竭诚欢迎世界各地的业界好友光临指导，洽谈合作。【电话/微信咨询：陈经理18068546632】抛光处理：       Domestic selection of major brands - Guosheng trademark Changzhou Tongdeli, patented technology, craftsmanship and quality. The spirit of craftsmanship is a treasure of China, a crystallization of our national culture, and the soul of the Chinese nation.　　Sliding rod rotary valve/star shaped discharge valve/shut-off fan unloader/rotary feeder Main structure: metal shell; Material contact parts: lined with ceramic, ceramic alumina, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Size: DN50~~Non standard customization.　　The cleaning sliding rod rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as lithium batteries, chemicals, pharmaceuticals, and food, as well as working in places where materials are frequently replaced. This product is benchmarked against top global brands of rotary valves, with better performance, price, and delivery time!　　Characteristics of cleaning type rotary valve: Material bonding equipment, can be quickly cleaned and reset. Stability is superior to other detachable valves, and the rotor can be pulled out in place. Disassembly before cleaning: Release the screw handle on the movable end cover, pull out the end cover and rotor together along the column, release the screw handle on the shaft end, and remove the rotor. After cleaning, install the impeller (rotate the impeller to engage the spline teeth), push in the end cover (rotate the movable shaft handle to engage the spline teeth), and tighten the bolt handle.　　Sliding rod rotary valves are mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, chemical powders/particles, food, plastics, etc.

　　滑杆星型旋转阀/卸料阀/关风机卸料器/旋转给料阀主要结构：外壳金属;物料接触部分：内衬陶瓷、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢。　　滑杆式旋转阀主要用于输送锂电池正极材料、磷酸铁锂、三元材料、化工粉料/颗粒、食品、塑料等。　　清洗型旋转阀特点：物料粘接设备，可以快速清理，快速复位。稳定性优于其他开拆式阀门，可原地抽出转子。松开活动端盖上的螺旋手柄，沿柱将端盖和转子一起拉出，松开轴端的螺旋手柄，取出转子。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。【电话/微信咨询：陈经理18068546632】　　快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于锂电、化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。本产品对标全球一线品牌的旋转阀，性能更优，价格&交期更好!　　公司在强化企业管理的基础上，依靠科技进步提高技术含量，先进的生产加工设备，领 先的管理理念，高素质的员工团队，有效的质量保障体系和完善的售后服务，为制造高品质的产品提供可靠的保证，极大的满足了各行业的需求，深受广大客户的信赖。【电话/微信咨询：陈经理18068546632】　　同得利秉承以下服务承诺:　　服务目标：服务质量赢得用户满意。　　严格控制对产品性能的检测，待产品被确认合格后再出厂发货。　　提供的产品符合报价文件承诺和所签合同规定的技术要求。　　物美价廉，具有输送系统完全密闭，可以避免输送物料的受潮、污损或混入异物等优势，常用于锂电/化工/药材/食品/塑料/钢厂/电厂/矿山/水泥/环保等行业。　　全新的铸造方法用于改善外表面光洁度和铸造完整性，阀体外壳强度更高。【电话/微信咨询：陈经理18068546632】           《扫二维码-添加 陈经理 微信-咨询滑杆式旋转阀》　　Sliding rod star shaped rotary valve/discharge valve/shut-off fan unloader/rotary feeding valve Main structure: metal shell; Material contact parts: lined with ceramic, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Sliding rod rotary valves are mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, chemical powders/particles, food, plastics, etc.　　Characteristics of cleaning type rotary valve: Material bonding equipment, can be quickly cleaned and reset. Stability is superior to other detachable valves, and the rotor can be pulled out in place. Release the screw handle on the movable end cover, pull out the end cover and rotor together along the column, release the screw handle on the shaft end, and remove the rotor. After cleaning, install the impeller (rotate the impeller to engage the spline teeth), push in the end cover (rotate the movable shaft handle to engage the spline teeth), and tighten the bolt handle.　　The rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as lithium batteries, chemicals, pharmaceuticals, and food, as well as working in places where materials are frequently replaced. This product is benchmarked against top global brands of rotary valves, with better performance, price, and delivery time!　　On the basis of strengthening enterprise management, the company relies on technological progress to improve its technological content, advanced production and processing equipment, leading management concepts, high-quality employee team, effective quality assurance system and perfect after-sales service, providing reliable guarantees for manufacturing high-quality products, greatly meeting the needs of various industries, and deeply trusted by customers.

　　快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。　　可拆卸叶轮：便于快速拆卸清洗旋转阀的物料接触面。　　驱动方式：链驱动/马达直连驱动。　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)　　侧快拆旋转阀材质：不锈钢304-316、四氟、尼龙、聚氨酯、陶瓷、特氟龙、钛合金、铝合金、不锈钢。【电话/微信咨询：陈经理 18068546632】　　侧快拆式旋转阀拆卸：松开固定螺栓，打开端盖门，抽出转子，清洗后转子推入壳体内，旋紧定位螺栓。　　非电机侧的阀体端盖，可快速拆卸并作为清洁时的操作入口，拆卸时可由现场操作人员手动完成，无需特殊工具。　　提供各种标准的阀体表面处理标准，以满足洁净应用。　　常用型号：2L  DN150  转速24转/分   电机功率0.75KW　　6L  DN200  转速24转/分   电机功率0.75KW　　12L DN250  转速24转/分   电机功率1.1KW　　16L DN300  转速24转/分   电机功率1.5KW　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。【电话/微信咨询：陈经理 18068546632】          《扫二维码-添加 陈经理 微信-咨询侧快拆旋转阀》　　The rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.　　Detachable impeller: facilitates quick disassembly and cleaning of the material contact surface of the rotary valve.　　Drive mode: chain drive/direct motor drive.　　Power configuration: Cycloid pinwheel reducer, Y series motor (can be configured according to customer's specified power)　　Material of side quick release rotary valve: stainless steel 304-316. PTFE, nylon, polyurethane, ceramic, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Dismantling of side quick release rotary valve: Loosen the fixing bolts, open the end cover door, extract the rotor, clean it, push the rotor into the housing, and tighten the positioning bolts.　　The valve body end cover on the non motor side can be quickly disassembled and used as an operating inlet for cleaning. The disassembly can be manually completed by on-site operators without the need for special tools.　　Provide various standard valve body surface treatment standards to meet clean applications.

　　输送锂电正负极材料，三元材料，磷酸铁锂等，用什么材质比较好，防金属接触，禁铜锌，同得利推荐不锈钢304/316内衬四氟也是不错的选择。输送化工原料，粉体或颗粒状，有腐蚀性(如强酸、强碱、强氧化剂等)亦可选内衬四氟旋转阀，如物料有粘性，搭配侧快拆或滑杆式，可快速清洗叶轮，快速复位。　　What is the best material for transporting lithium positive and negative electrode materials, ternary materials, lithium iron phosphate, etc.? It should prevent metal contact, prohibit copper and zinc, and Tongdeli recommends stainless steel 304/316 lined with PTFE as a good choice. Transporting chemical raw materials in powder or granular form, which are corrosive (such as strong acids, strong alkalis, strong oxidants, etc.), can also be equipped with a PTFE rotary valve lining. If the material is viscous, it can be paired with a side quick release or sliding rod type to quickly clean the impeller and reset it.　　旋转阀内衬四氟(聚四氟乙烯 PTFE)的核心作用是‌利用氟塑料极 致化学惰性隔离腐蚀介质，同时凭借低摩擦系数保障旋转启闭灵活与密封可靠‌。‌‌　　The core function of PTFE lining in rotary valves is to utilize the extreme chemical inertness of fluoroplastics to isolate corrosive media, while ensuring flexible opening and closing and reliable sealing with low friction coefficient. ‌‌　　快拆滑杆式旋转阀内衬四氟核心功能：　　1、极 致耐腐蚀隔离‌：PTFE几乎耐受所有强酸(如浓硫酸、氢氟酸、王水)、强碱及有机溶剂，解决金属材质易腐蚀失效难题 。　　2、防金属接触：禁铜锌，内衬后形成物理屏障，阻断锂电池原料/化工物料腐蚀性介质与金属阀体/阀芯接触。　　3、优异密封与防粘‌：表面张力极小具有不粘性，防止介质结晶或挂壁堵塞流道;配合弹性变形能力可实现紧密贴合，达到零泄漏标准(ANSI Class VI)，尤其适合频繁启闭场景 。　　4、减摩润滑与扭矩降低‌：PTFE动静摩擦系数极低，显著减少旋转部件与阀座间的摩擦阻力，降低操作扭矩，防止卡涩，延长机械寿命 。　　5、宽温适应性‌：可在 -196℃至 +200℃(部分工艺可达 250℃)范围内稳定工作，满足多数化工极端温度需求，同时保持化学稳定性 。‌‌　　6、快速清洗维护‌：针对物料粘接，快拆清理，快速复位。采用滑杆式锁紧机构，可徒手或简单操作迅速打开阀体，转子易拆卸，清洗便捷，无卫生死角，符合食品、医药级 GMP 要求 。【电话/微信咨询：陈经理18068546632】　　常州同得利/江苏同得利专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。　　部分客户需求：　　锂电行业，旋转阀壳体304.内衬四氟，转子全四氟，主轴2205双相不锈钢，转子与阀体单边间隙0.25.主轴密封为气密封(盘根+油封+配气环)，旋转阀容积4L，转速25转每分钟，电机皖南非变频电机，减速机国贸。　　锂电原料输送，Q≥1t/h(物料堆积密度0.6g/cm³)，DN200旋转阀(关风机)SUS304内衬四氟，变频电机防护等级IP55变频器调速(功率1.1kW,电流2.67A,冷却风扇功率42W,电流0.1A)。　　内衬四氟星型卸料器，物料：结晶葡萄糖，温度70-80℃，处理量10T/H。水分10%，容重650g/L。自重下料，需要上圆下方，304内衬四氟。卸料器闭风器总高580mm，闭风器本体高500mm，视镜高80mm,为天圆地方造型，上部法兰为4螺孔，孔直径12mm,中心丝距305mm,下部底座为4螺孔，孔直径14mm,同边中心丝距250mm，左右中心丝距310mm。配国贸硬斜齿的减速机，士林电机。　　储能行业用，物料为压滤后的湿料,片状,含水10%,物料很软,DN250管道卸料阀,材质304内衬聚四氟乙烯PTFE,转子也是四氟,电机直驱,卸料阀轴密封均采用聚四氟乙烯盘根,轴密封采用盘根加气密封。　　物料：制药粉料,常温,材质304内衬四氟,进出口DN200.12升/转,叶轮:开式6片铸造U型,外置轴承,轴端密封:四氟乙烯填料,减速机电机:摆线BI-35-1.1kw(防爆)。　　四氟旋转阀+破拱阀。衬四氟的旋转阀，要求DN100.不锈钢衬四氟，固体下料速度1kg/min，阀体上有氮气吹扫管口DN25.输送含溴元素物料。配套对应的破拱器，防止物料不下料形成拱桥，破拱也衬四氟。　　星型卸料阀衬四氟，进料口DN50国标法兰，电机防爆，1.5kw，输送固料量1m3/hr，物料:五硫化二磷，有腐蚀性，安装在反应釜下方，反应釜是要抽真空。密封要好，材质316L或者衬四氟比较好。　　物料：化工厂消毒粉，之前用不锈钢有腐蚀，需要耐腐蚀型高的，温度七八十度，尺寸DN300.自重下料，减速机SEW-EURODRIVE、NORD(诺德)，电机卧龙，ABB，西门子。         《扫二维码-添加 陈经理 微信-咨询内衬四氟滑杆式旋转阀》　　Quick release sliding rod rotary valve lined with PTFE core function:　　1. Ultimate corrosion resistance isolation: PTFE can withstand almost all strong acids (such as concentrated sulfuric acid, hydrofluoric acid, aqua regia), strong alkalis, and organic solvents, solving the problem of metal material corrosion and failure.　　2. Anti metal contact: Copper and zinc are prohibited, and a physical barrier is formed after lining to block the contact between corrosive media of lithium battery raw materials/chemical materials and metal valve bodies/cores.　　3. Excellent sealing and anti sticking: With extremely low surface tension and non stick properties, it prevents medium crystallization or wall blockage of the flow channel; Combined with elastic deformation ability, it can achieve a tight fit and meet the zero leakage standard (ANSI Class VI), especially suitable for frequent opening and closing scenarios.　　4. Friction reducing lubrication and torque reduction: PTFE has an extremely low coefficient of dynamic and static friction, significantly reducing the frictional resistance between rotating parts and valve seats, lowering operating torque, preventing jamming, and extending mechanical life.　　5. Wide temperature adaptability: It can work stably within the range of -196 ℃ to+200 ℃ (some processes can reach 250 ℃), meeting the extreme temperature requirements of most chemical industries while maintaining chemical stability. ‌‌　　6. Quick cleaning and maintenance: for material bonding, quick disassembly and cleaning, quick reset. Adopting a sliding rod locking mechanism, the valve body can be quickly opened by hand or with simple operation. The rotor is easy to disassemble, easy to clean, and has no hygiene dead corners, meeting the requirements of food and pharmaceutical GMP.　　Changzhou Tongdeli/Jiangsu Tongdeli specializes in the production of (B) GFY and YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high-temperature and high-pressure rotary valves, high-temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE nylon polyurethane, arch breakers, silo scraper crushers, dispersing and crushing valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.　　Partial customer requirements:　　In the lithium battery industry, the rotary valve housing is made of 304. lined with PTFE, the rotor is made of PTFE, the main shaft is made of 2205 duplex stainless steel, and the single-sided gap between the rotor and the valve body is 0.25. The main shaft seal is gas sealed (packing+oil seal+air distribution ring), the rotary valve volume is 4L, the speed is 25 revolutions per minute, the motor is Wannana frequency converter, and the reducer is from Guomao.　　Lithium battery raw material transportation, Q ≥ 1t/h (material bulk density 0.6g/cm ³), DN200 rotary valve (closed fan) SUS304 lined with PTFE, variable frequency motor protection level IP55. variable frequency drive speed (power 1.1kW, current 2.67A, cooling fan power 42W, current 0.1A).　　Lined PTFE star shaped unloader, material: crystalline glucose, temperature 70-80 ℃, processing capacity 10T/H. Moisture content 10%, bulk density 650g/L. Self weight cutting requires upper circle and lower part, lined with 304 PTFE. The total height of the air damper for the unloader is 580mm, with a body height of 500mm and a mirror height of 80mm. It is designed with a round sky and square shape. The upper flange has 4 screw holes with a diameter of 12mm and a center to center distance of 305mm. The lower base has 4 screw holes with a diameter of 14mm and a center to center distance of 250mm on the same side and 310mm on the left and right sides. It is equipped with a reducer with hard bevel teeth and a Shilin motor.　　Used in the energy storage industry, the material is wet material after pressure filtration, in the form of flakes, with a water content of 10%, and the material is very soft. The DN250 pipeline discharge valve is made of 304 material lined with polytetrafluoroethylene PTFE, and the rotor is also made of PTFE. The motor is directly driven, and the discharge valve shaft seal adopts polytetrafluoroethylene packing, and the shaft seal adopts packing and airtight seal.　　Material: Pharmaceutical powder, at room temperature, material 304 lined with PTFE, inlet and outlet DN200. 12 liters/revolution, impeller: open type 6-piece cast U-shaped, external bearing, shaft end seal: PTFE packing, reducer motor: cycloidal BI-35-1.1kw (explosion-proof).　　PTFE rotary valve+arch breaking valve. A rotary valve lined with PTFE is required to be DN100. made of stainless steel lined with PTFE, with a solid feeding speed of 1kg/min. The valve body is equipped with a DN25 nitrogen blowing nozzle. Transport materials containing bromine elements. Corresponding arch breakers are provided to prevent the formation of arch bridges due to material failure, and the arch is also lined with PTFE.　　Star shaped discharge valve lined with PTFE, DN50 national standard flange for feed inlet, explosion-proof motor, 1.5kw, solid material conveying capacity of 1m3/hr, material: phosphorus pentasulfide, corrosive, installed below the reaction vessel, which needs to be evacuated. Good sealing, material 316L or PTFE lining is better.　　Material: Chemical plant disinfectant powder, previously made of stainless steel with corrosion resistance, requires high corrosion resistance, temperature of 70-80 degrees, size DN300. self weight cutting, reducer SEW-EURODRIVE, NORD, motor Wolong, ABB， Siemens

　　滑杆式旋转阀/卸料阀/星型卸料器/旋转给料器主要结构：外壳金属;物料接触部分：内衬陶瓷、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢。　　滑杆式旋转阀主要用于输送锂电池正极材料、磷酸铁锂、三元材料、化工、食品、制药、塑料等。　　滑杆式旋转阀特点：物料粘接设备，可以快速清理，快速复位。　　稳定性优于其他开拆式阀门，可原地抽出转子。　　清洗前的拆卸：松开螺栓手柄，沿导柱将端盖轻轻拉至极限，抽出叶轮，双手握住叶轮两端抽颈取出。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。　　驱动方式：链驱动/马达直连驱动。　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)【电话/微信咨询：陈经理18068546632】        内衬陶瓷旋转阀具有平滑的表面和优异的耐腐蚀性，不会吸附有害物质和细菌。可以保持储存和传输介质的洁净，提高生产质量和安全性。陶瓷内衬具有优异的电绝缘性和高硬度，可以提高旋转阀的性能和稳定性，并减少旋转卸料阀的磨损和损坏。陶瓷内衬还可以起到防爆的作用。由于陶瓷内衬具有较高的抗压强度和耐冲击性，它可以有效地抵御爆炸或高压气体产生的冲击和破坏。　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。【电话/微信咨询：陈经理 18068546632】        《扫二维码-添加 陈经理 微信-咨询滑杆式陶瓷旋转阀》　　Sliding rod rotary valve/discharge valve/star shaped unloader/rotary feeder Main structure: metal shell; Material contact parts: lined with ceramic, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Sliding rod rotary valves are mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, chemical, food, pharmaceutical, plastic, etc.　　Features of sliding rod rotary valve: Material bonding equipment, can be quickly cleaned and reset.　　Stability is superior to other detachable valves, and the rotor can be pulled out in place.　　Disassembly before cleaning: Loosen the bolt handle, gently pull the end cover along the guide column to the limit, extract the impeller, and hold both ends of the impeller with both hands to remove the neck. After cleaning, install the impeller (rotate the impeller to engage the spline teeth), push in the end cover (rotate the movable shaft handle to engage the spline teeth), and tighten the bolt handle.　　Drive mode: chain drive/direct motor drive.　　Power configuration: Cycloid pinwheel reducer, Y series motor (can be configured according to customer's specified power)

　　快速清洗型旋转阀/星型卸料器广泛应用于食品、医药、化工对卫生高要求场合，以及更换物料频繁需要清理卸料的系统。按操作形式可分为滑杆式和快开式，易于快速清理叶腔中粘性物料，安装方便。　　快开门式星型卸料器/卸料阀/旋转阀/旋转供料器：松开固定螺栓，打开端盖门，抽出转子，清洗后转子推入壳体内，旋紧定位螺栓。【电话/微信咨询：陈经理 18068546632】　　驱动方式：链驱动/马达直连驱动。　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)　　材质：物料接触部分：内衬聚氨酯、尼龙、四氟、陶瓷、特氟龙、钛合金、铝合金、不锈钢。【电话/微信咨询：陈经理 18068546632】        《扫二维码-添加 陈经理 微信-咨询快拆式星型卸料器》　　Quick cleaning rotary valves/star shaped unloaders are widely used in food, medicine, chemical industries with high hygiene requirements, as well as systems that require frequent material replacement and discharge cleaning. According to the operating form, it can be divided into sliding rod type and quick opening type, which is easy to quickly clean viscous materials in the blade cavity and easy to install.　　Quick opening star shaped unloader/discharge valve/rotary valve/rotary feeder: Loosen the fixing bolts, open the end cover door, extract the rotor, clean it, push the rotor into the housing, and tighten the positioning bolts.　　Drive mode: chain drive/direct motor drive.　　Power configuration: Cycloid pinwheel reducer, Y series motor (can be configured according to customer's specified power)　　Material: Material contact parts: lined with polyurethane, nylon, PTFE, ceramic, PTFE, titanium alloy, aluminum alloy, stainless steel.

　　风送滑杆式旋转阀/卸料阀/星型卸料器/旋转给料阀/旋转供料器主要结构：外壳金属;物料接触部分：内衬陶瓷(也可尼龙、四氟、特氟龙等)。　　主要用于食品、药材、锂电、化工、塑料原料输送。　　特点：针对物料粘接，风力直吹转子清理。快拆清理，快速复位。　　风送滑杆式旋转阀主要材料：不锈钢304-316.陶瓷氧化铝，钛合金、铝合金、陶瓷系列、尼龙、四氟、不锈钢等。【电话/微信咨询：陈经理 18068546632】　　快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。　　滑杆式旋转阀：清洗前的拆卸。松开活动瑞盖上的螺旋手柄，沿柱将瑞盖和转子一起拉出，松开轴端的螺旋手柄，取出转子。　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。【电话/微信咨询：陈经理 18068546632】          《扫二维码-添加 陈经理 微信-咨询风送滑杆式旋转阀》　　Wind driven sliding rod rotary valve/discharge valve/star shaped unloader/rotary feeding valve/rotary feeder Main structure: metal shell; Material contact part: lined with ceramic (also nylon, PTFE, PTFE, etc.).　　Mainly used for conveying food, medicinal materials, lithium batteries, chemicals, and plastic raw materials.　　Features: Targeting material bonding, wind blown rotor cleaning. Quick disassembly and cleaning, quick reset.　　The main materials of the air supply sliding rod rotary valve include stainless steel 304-316. ceramic alumina, titanium alloy, aluminum alloy, ceramic series, nylon, PTFE, stainless steel, etc.　　The rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.　　Sliding rod rotary valve: disassembly before cleaning. Release the spiral handle on the activity cover, pull out the cover and rotor together along the column, release the spiral handle on the shaft end, and remove the rotor.　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production/customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valves are capable of handling various types of particles, flakes, blocks, adhesives, powders, ultrafine powders, etc. in industries such as lithium batteries, steel mills, power plants, cement, mining, environmental protection, plastics, chemical, food, and pharmaceuticals.

　　侧快拆清洗型旋转阀主要结构：外壳金属;物料接触部分：内衬聚氨酯、尼龙、四氟、陶瓷、特氟龙、钛合金、铝合金、不锈钢。　　侧快拆旋转阀主要用于输送锂电池正极材料、磷酸铁锂、三元材料、化工、食品、制药、塑料等。　　特点：物料粘接设备，可以快速清理，快速复位。　　稳定性优于其他开拆式阀门，可原地抽出转子。【电话/微信咨询：陈经理18068546632】         《扫二维码-添加 陈经理 微信-咨询侧快拆旋转阀》　　The main structure of the side quick release cleaning rotary valve is: metal shell; Material contact parts: lined with polyurethane, nylon, PTFE, ceramic, PTFE, titanium alloy, aluminum alloy, stainless steel.　　The side quick release rotary valve is mainly used for transporting lithium battery positive electrode materials, lithium iron phosphate, ternary materials, chemical, food, pharmaceutical, plastic, etc.　　Features: Material bonding equipment that can be quickly cleaned and reset.　　Stability is superior to other detachable valves, and the rotor can be pulled out in place.

【清洗型】水冷耐高温滑杆式旋转阀，此产品由本公司自主研发生产，其特点集聚一身：水冷式耐高温＜1000℃，鹰嘴防卡防堵，滑杆式可清洗叶轮，高卫生标准。　　快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。　　滑杆式旋转阀可拆卸叶轮：便于快速拆卸清洗旋转阀的物料接触面。　　驱动方式：链驱动/马达直连驱动。　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)　　滑杆式旋转阀/星型卸料阀：清洗前的拆卸。松开螺栓手柄，沿导柱将端盖轻轻拉至极限，抽出叶轮，双手握住叶轮两端抽颈取出。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。【电话/微信咨询：陈经理18068546632】　　水冷耐高温旋转阀：适用于温度过高的物料，很好的降温。　　阀体：采用整体浇铸于不锈钢全 面通水降温。　　端盖采用全 面通水降温，避免轴承传递高温。　　叶轮主轴采用全 面通水降温，避免高温形变，影响同心度。　　我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开阀、清洁阀、风送式旋转阀等产品。广泛应用于锂电池、粮食、饲料、石油化工、制药、淀粉、油脂、化工干燥、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。【电话/微信咨询：陈经理18068546632】     《扫二维码-添加 陈经理 微信-咨询水冷耐高温滑杆式旋转阀》　　Sliding rod rotary valve/star discharge valve: disassembly before cleaning. Release the bolt handle, gently pull the end cover along the guide column to the limit, extract the impeller, and hold both ends of the impeller with both hands to remove the neck. After cleaning, install the impeller (rotate the impeller to engage the spline teeth), push in the end cover (rotate the movable shaft handle to engage the spline teeth), and tighten the bolt handle.　　Water cooled high-temperature resistant rotary valve: suitable for materials with excessively high temperatures, providing excellent cooling.　　Valve body: It is cast as a whole in stainless steel and fully cooled by water flow.　　The end cover adopts comprehensive water cooling to avoid bearing transmission of high temperature.　　The impeller spindle adopts comprehensive water cooling to avoid high-temperature deformation and affect concentricity.　　Our company specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening valves, cleaning valves, pneumatic rotary valves and other products. Widely used in equipment for industries such as lithium batteries, grain, feed, petrochemicals, pharmaceuticals, starch, oils and fats, chemical drying, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　侧快拆卸料阀/星型旋转阀/关风机卸料器主要结构：外壳金属;物料接触部分：内衬聚氨酯、尼龙、四氟、陶瓷、特氟龙、钛合金、铝合金、不锈钢。　　主要用于输送锂电池正极材料、磷酸铁锂、三元材料、化工、食品、制药等。　　特点：物料粘接设备，可以快速清理，快速复位。　　稳定性优于其他开拆式阀门，可原地抽出转子进行清洗。【电话/微信咨询：陈经理18068546632】　　卸料阀内衬是指在阀门衬里加一层具有一定特性的防腐、耐磨材料进行衬里处理的技术。常见的衬里材料有陶瓷、特氟龙、尼龙、聚氨酯、聚四氟乙烯(PTFE)等。　　内衬聚氨酯卸料阀的设计进一步增强了这种旋转卸料阀门的功能性和耐用性。‌聚氨酯作为一种耐磨、‌耐腐蚀、防金属接触的材料，‌能够有效地抵抗流体中的腐蚀性成分，‌保护阀门内部不受损害。‌同时，‌聚氨酯的耐磨性也延长了旋转阀门的使用寿命，‌减少了维护和更换的频率。‌【电话/微信咨询：陈经理18068546632】      《扫二维码-添加 陈经理 微信-咨询锂电内衬聚氨酯卸料阀》　　Side quick disassembly material valve/star shaped rotary valve/shut-off fan unloader main structure: metal shell; Material contact parts: lined with polyurethane, nylon, PTFE, ceramic, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Mainly used for transporting positive electrode materials of lithium batteries, lithium iron phosphate, ternary materials, chemicals, food, pharmaceuticals, etc.　　Features: Material bonding equipment that can be quickly cleaned and reset.　　Stability is superior to other detachable valves, and the rotor can be removed in place for cleaning.　　Unloading valve lining refers to the technology of adding a layer of anti-corrosion and wear-resistant material with certain characteristics to the valve lining for lining treatment. Common lining materials include ceramics, PTFE, nylon, polyurethane, polytetrafluoroethylene (PTFE), etc.　　The design of the polyurethane lined discharge valve further enhances the functionality and durability of this rotary discharge valve. Polyurethane, as a wear-resistant, corrosion-resistant, and metal contact resistant material, can effectively resist corrosive components in fluids and protect the interior of valves from damage. Meanwhile, the wear resistance of polyurethane also extends the service life of rotary valves and reduces the frequency of maintenance and replacement.

【锂电旋转阀】DN200清洗型旋转阀-耐腐蚀，耐磨，防金属接触本产品特性：特氟龙法兰+尼龙叶轮+侧快拆式+清洗型拆卸方法：用扳手松开开门端盖上的四个螺栓，把叶轮拉出清理。安装方法：把清理后的叶轮推进阀体内部，轻轻转动叶轮，使叶轮装进空心轴内部，确定安装好后，用扳手拧紧螺栓。旋转阀安装时应保证垂直、水平安装，请勿偏斜。使用前应检查电源正确接入，确保无误。【电话/微信咨询：陈经理18068546632】        《扫二维码-添加 陈经理 微信-咨询锂电清洗型旋转阀》

　　星型卸料器/卸料阀是气力输送系统中的关键设备。也是除尘和加料系统的常用设备。根据特性、用途和使用条件的不同，星型卸料器有多种结构型式，星型卸料器的选型要根据被输送物料的特性如堆积密度、物料温度、吸潮性、含水量、粒径、流动性、硬度、腐蚀性等来决定的。　　常州同得利机械厂主要制造适用于粘性的，含坚硬杂质的以及高温高压或高真空情况下使用的特殊结构的星型卸料器。以及超小尺寸的卸料器，都是非常规结构特殊非标定制。【电话/微信咨询：陈经理 18068546632】　　不锈钢卸料器可应用于食品等有高卫生要求的场合，拆卸方便，易于进行清理工作，符合高要求的卫生标准。操作方便，无死点。     《扫二维码-添加 陈经理 微信-咨询食品级卸料阀》　　Star shaped unloader/discharge valve is a key equipment in pneumatic conveying systems. It is also a commonly used equipment for dust removal and feeding systems. According to different characteristics, purposes, and usage conditions, star shaped unloaders have various structural types. The selection of star shaped unloaders should be determined based on the characteristics of the conveyed material, such as bulk density, material temperature, moisture absorption, moisture content, particle size, flowability, hardness, corrosiveness, etc.　　Changzhou Tongdeli Machinery Factory mainly manufactures star shaped unloaders with special structures suitable for viscous, hard impurity containing, and high-temperature, high-pressure, or high vacuum conditions. And the ultra small size unloaders are all customized with unconventional structures and special non-standard designs.　　Stainless steel unloaders can be used in places with high hygiene requirements such as food. They are easy to disassemble and clean, meeting high hygiene standards. Easy to operate, no dead spots.
