DS-F-6L-DN200电动锁气器/锁气阀/ 电动锁气器,锁气阀,旋转阀,卸料阀,关风机
产品介绍电动锁气器/锁气阀适用于火力发电厂除尘器、空气预热器,省煤器等设备的出料口,或干灰输送管道中,作锁气及均匀给料。也可用于化工厂、水泥厂、粮食加工厂部门的气力运输管道中。 电动锁气器/锁气阀结构与型式: 主要结构有壳体、转子、传动结构(摆线针轮减速机、电动机)。【电话/微信咨询:陈经理18068546632】 装置型式主要有两种: 转动机构与转子直线联接,一字排开--直连式。 转动机构与转子用链条搭接--平行轴线式。 在直连式中,又可细分为带角铁支架以配装卧式减速机(加注B)以及经联轴节直接联接立式减速机的型式(加注A) 备注:可定制非标型。【电话/微信咨询:陈经理18068546632】 《扫二维码-添加 陈经理 微信-咨询电动锁气器/锁气阀》 Electric air lock/air lock valve is suitable for the discharge ports of dust collectors, air preheaters, economizers and other equipment in thermal power plants, or in dry ash conveying pipelines, for air lock and uniform feeding. It can also be used in pneumatic transportation pipelines of chemical plants, cement plants, and grain processing plants. Electric air lock/lock valve structure and type: The main structures include shell, rotor, and transmission structure (cycloidal pinwheel reducer, electric motor). There are two main types of devices: The rotating mechanism is linearly connected to the rotor, arranged in a straight line - direct connection. The rotating mechanism and rotor are overlapped with chains - parallel axis type. In direct connection, it can be further divided into two types: those with angle iron brackets to install horizontal reducers (note B) and those directly connected to vertical reducers through couplings (note A) Note: Non standard models can be customized.查看详情 +
-
高密封锁气阀/电动锁气器/ 旋转阀,卸料阀,锁气阀,电动锁气器,关风机
产品介绍锁气阀/电动锁气器是气力输送系统中的关键设备,也是除尘和加料系统的常用设备。根据物料的特性、用途和使用条件的不同,电动锁气器有多种结构形式。电动锁气器的选型要依据被输送物料的特性如粒度大小、黏附性、温度、湿度来决定的。【电话/微信咨询:陈经理18068546632】 锁气阀/电动锁气器用途: 电动锁气器适用于火力发电厂粉煤灰、煤粉、石膏粉等物料中近距离(300米内)气力输送系统。也可用于水泥、冶金、化工等其他行业中粉状物料的低压气力输送系统。 常州同得利机械厂主要制造适用于粘性的,含坚硬杂质的以及高温高压或高真空情况下使用的电动锁气器。以及小尺寸的电动锁气器,都是非常规结构非标定制。【电话/微信咨询:陈经理18068546632】 《扫二维码-添加 陈经理 微信-咨询锁气阀/电动锁气器》 Lock valve/electric lock valve is a key equipment in pneumatic conveying system and a commonly used equipment in dust removal and feeding system. According to the characteristics, uses, and usage conditions of materials, electric air locks have various structural forms. The selection of electric air locks should be based on the characteristics of the conveyed material, such as particle size, adhesion, temperature, and humidity. Application of air lock valve/electric air lock: Electric air locks are suitable for close range (within 300 meters) pneumatic conveying systems for materials such as fly ash, coal powder, gypsum powder, etc. in thermal power plants. It can also be used in low-pressure pneumatic conveying systems for powdered materials in other industries such as cement, metallurgy, and chemical engineering. Changzhou Tongdeli Machinery Factory mainly manufactures electric air locks suitable for use in viscous, hard impurity containing, high-temperature, high-pressure, or high vacuum situations. And small-sized electric air locks are all customized with unconventional structures and non-standard specifications.查看详情 +
-
锁气阀/旋转阀/电动锁气器/ 星型卸料阀,旋转阀,锁气阀,电动锁气器
产品介绍旋转供料器,也被称为旋转阀、星形卸料阀、关风机、锁气阀、旋转给料器、星型下料器、关风器、电动锁气器等,是一种散状物料输送的主要设备。它主要由主阀(壳体、端盖、叶轮、轴承、油封和集气管等)、电机减速机、防护装置组成。【电话/微信咨询:陈经理18068546632】 电动锁气器/锁气阀的工作原理主要是通过电机驱动叶轮旋转来实现物料的输送和锁气功能。具体来说: 电机传动:电动锁气器通过电机驱动减速机,进而带动阀体内的叶轮转子转动。 物料输送:叶轮的旋转使得物料从上一级管道或输送斜槽输送到设备中,然后通过叶轮的旋转将物料输送到下一级管道或收料设备。 锁气功能:在输送过程中,电动锁气器的叶轮不仅负责物料的输送,还起到密闭作用,防止气力输送过程中从出料口吸入空气,保证系统的正常运作。【电话/微信咨询:陈经理18068546632】 结构特点:电动锁气器的叶轮与壳体内壁的间隙很小,有效防止下方低压泵气流的上窜,具有良好的锁气效果;同时,叶轮采用耐磨材料制成,具有良好的密封性和耐用性。 总之,电动锁气器通过电机驱动叶轮的旋转来实现物料的连续均匀给料和气路的隔断,确保系统设备的使用需求得到满足,同时保证物料输送的安全和效率。【电话/微信咨询:陈经理18068546632】 《扫二维码-添加 陈经理 微信-咨询锁气阀/旋转阀》 The working principle of electric air lock/air lock valve is mainly to achieve material conveying and air lock function by driving the impeller to rotate through the motor. Specifically: Motor drive: The electric air lock drives the reducer through the motor, which in turn drives the impeller rotor inside the valve body to rotate. Material transportation: The rotation of the impeller causes the material to be transported from the previous pipeline or inclined conveyor to the equipment, and then the material is transported to the next pipeline or receiving equipment through the rotation of the impeller. Air locking function: During the conveying process, the impeller of the electric air lock is not only responsible for the transportation of materials, but also plays a sealing role to prevent air from being sucked in from the discharge port during pneumatic conveying, ensuring the normal operation of the system. Structural features: The gap between the impeller of the electric air lock and the inner wall of the housing is very small, effectively preventing the upward movement of the low-pressure pump airflow below, and having a good air lock effect; Meanwhile, the impeller is made of wear-resistant materials, which have good sealing and durability. In short, the electric air lock achieves continuous and uniform feeding of materials and separation of gas paths through the rotation of the impeller driven by the motor, ensuring that the usage requirements of the system equipment are met while ensuring the safety and efficiency of material transportation.查看详情 +
-
DN200锁气阀 / 卸料阀/ 电动锁气器,旋转阀,锁气阀,卸料阀,星型卸料器
产品介绍电动锁气器/锁气阀/星型卸料阀用于旋转卸料和均匀落料,主要用于粉料和小颗粒物料的气力送料,是由电动装置和气密壳体组成,即可起到均匀落料,也可起到气料分离的作用。 料仓内物料依靠自重或气力送料落入电动锁气器旋转的叶轮拨片中,随着叶轮不断旋转物料均匀落下方设备中,由于叶轮和壳体间隙,叶轮低速运行,防止气力顺流或逆向运动,气压稳定同时,在气力送料过程中即可起到供料作用,也可起到密封作用。【电话/微信咨询:陈经理18068546632】 电动锁气器两侧端盖设有平衡压力的联通管道,可进行压缩空气、氮气、氧气、氢气的注入,注入气体后,两侧气囊膨起,无论是气体、还是物料,均可实现零泄漏。【电话/微信咨询:陈经理18068546632】 《扫二维码-添加 陈经理 微信-咨询锁气阀/卸料阀》 Electric air lock/air lock valve/star shaped discharge valve is used for rotating discharge and uniform material dropping, mainly for pneumatic feeding of powder and small particle materials. It is composed of an electric device and an airtight shell, which can achieve uniform material dropping or gas separation. The materials in the silo are fed by their own weight or pneumatic force and fall into the rotating impeller blades of the electric air lock. As the impeller continues to rotate, the materials evenly fall into the equipment below. Due to the gap between the impeller and the housing, the impeller runs at low speed to prevent the pneumatic force from flowing in the same or opposite direction. At the same time, the air pressure is stable, and it can play a role in feeding and sealing during the pneumatic feeding process. The two end caps of the electric air lock are equipped with connecting pipes for balanced pressure, which can inject compressed air, nitrogen, oxygen, and hydrogen. After injecting gas, the airbags on both sides will inflate, achieving zero leakage for both gas and material.查看详情 +
-
DS-E-50L锁气阀/电动锁气器/ 锁气阀,电动锁气器,卸料阀,旋转阀,关风机
产品介绍本产品锁气阀/电动锁气器适用于火力发电厂除尘器、空气预热器,省煤器等设备的出料口,或干灰输送管道中,作锁气及均匀给料。也可用于化工厂、水泥厂、粮食加工厂部门的气力运输管道中。【电话/微信咨询:陈经理18068546632】 《扫二维码-添加 陈经理 微信-咨询锁气阀》 This product's air lock valve/electric air lock is suitable for the discharge ports of dust collectors, air preheaters, economizers and other equipment in thermal power plants, or in dry ash conveying pipelines, for air lock and uniform feeding. It can also be used in pneumatic transportation pipelines of chemical plants, cement plants, and grain processing plants.查看详情 +
