输送锂电正负极材料，三元材料，磷酸铁锂等，用什么材质比较好，防金属接触，禁铜锌，同得利推荐不锈钢304/316内衬四氟也是不错的选择。输送化工原料，粉体或颗粒状，有腐蚀性(如强酸、强碱、强氧化剂等)亦可选内衬四氟旋转阀，如物料有粘性，搭配侧快拆或滑杆式，可快速清洗叶轮，快速复位。

　　What is the best material for transporting lithium positive and negative electrode materials, ternary materials, lithium iron phosphate, etc.? It should prevent metal contact, prohibit copper and zinc, and Tongdeli recommends stainless steel 304/316 lined with PTFE as a good choice. Transporting chemical raw materials in powder or granular form, which are corrosive (such as strong acids, strong alkalis, strong oxidants, etc.), can also be equipped with a PTFE rotary valve lining. If the material is viscous, it can be paired with a side quick release or sliding rod type to quickly clean the impeller and reset it.

　　旋转阀内衬四氟(聚四氟乙烯 PTFE)的核心作用是‌利用氟塑料极 致化学惰性隔离腐蚀介质，同时凭借低摩擦系数保障旋转启闭灵活与密封可靠‌。‌‌

　　The core function of PTFE lining in rotary valves is to utilize the extreme chemical inertness of fluoroplastics to isolate corrosive media, while ensuring flexible opening and closing and reliable sealing with low friction coefficient. ‌‌

　　快拆滑杆式旋转阀内衬四氟核心功能：

　　1、极 致耐腐蚀隔离‌：PTFE几乎耐受所有强酸(如浓硫酸、氢氟酸、王水)、强碱及有机溶剂，解决金属材质易腐蚀失效难题 。

　　2、防金属接触：禁铜锌，内衬后形成物理屏障，阻断锂电池原料/化工物料腐蚀性介质与金属阀体/阀芯接触。

　　3、优异密封与防粘‌：表面张力极小具有不粘性，防止介质结晶或挂壁堵塞流道;配合弹性变形能力可实现紧密贴合，达到零泄漏标准(ANSI Class VI)，尤其适合频繁启闭场景 。

　　4、减摩润滑与扭矩降低‌：PTFE动静摩擦系数极低，显著减少旋转部件与阀座间的摩擦阻力，降低操作扭矩，防止卡涩，延长机械寿命 。

　　5、宽温适应性‌：可在 -196℃至 +200℃(部分工艺可达 250℃)范围内稳定工作，满足多数化工极端温度需求，同时保持化学稳定性 。‌‌

　　6、快速清洗维护‌：针对物料粘接，快拆清理，快速复位。采用滑杆式锁紧机构，可徒手或简单操作迅速打开阀体，转子易拆卸，清洗便捷，无卫生死角，符合食品、医药级 GMP 要求 。【电话/微信咨询：陈经理18068546632】

　　常州同得利/江苏同得利专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。

　　部分客户需求：

　　锂电行业，旋转阀壳体304.内衬四氟，转子全四氟，主轴2205双相不锈钢，转子与阀体单边间隙0.25.主轴密封为气密封(盘根+油封+配气环)，旋转阀容积4L，转速25转每分钟，电机皖南非变频电机，减速机国贸。

　　锂电原料输送，Q≥1t/h(物料堆积密度0.6g/cm³)，DN200旋转阀(关风机)SUS304内衬四氟，变频电机防护等级IP55变频器调速(功率1.1kW,电流2.67A,冷却风扇功率42W,电流0.1A)。

　　内衬四氟星型卸料器，物料：结晶葡萄糖，温度70-80℃，处理量10T/H。水分10%，容重650g/L。自重下料，需要上圆下方，304内衬四氟。卸料器闭风器总高580mm，闭风器本体高500mm，视镜高80mm,为天圆地方造型，上部法兰为4螺孔，孔直径12mm,中心丝距305mm,下部底座为4螺孔，孔直径14mm,同边中心丝距250mm，左右中心丝距310mm。配国贸硬斜齿的减速机，士林电机。

　　储能行业用，物料为压滤后的湿料,片状,含水10%,物料很软,DN250管道卸料阀,材质304内衬聚四氟乙烯PTFE,转子也是四氟,电机直驱,卸料阀轴密封均采用聚四氟乙烯盘根,轴密封采用盘根加气密封。

　　物料：制药粉料,常温,材质304内衬四氟,进出口DN200.12升/转,叶轮:开式6片铸造U型,外置轴承,轴端密封:四氟乙烯填料,减速机电机:摆线BI-35-1.1kw(防爆)。

　　四氟旋转阀+破拱阀。衬四氟的旋转阀，要求DN100.不锈钢衬四氟，固体下料速度1kg/min，阀体上有氮气吹扫管口DN25.输送含溴元素物料。配套对应的破拱器，防止物料不下料形成拱桥，破拱也衬四氟。

　　星型卸料阀衬四氟，进料口DN50国标法兰，电机防爆，1.5kw，输送固料量1m3/hr，物料:五硫化二磷，有腐蚀性，安装在反应釜下方，反应釜是要抽真空。密封要好，材质316L或者衬四氟比较好。

　　物料：化工厂消毒粉，之前用不锈钢有腐蚀，需要耐腐蚀型高的，温度七八十度，尺寸DN300.自重下料，减速机SEW-EURODRIVE、NORD(诺德)，电机卧龙，ABB，西门子。

         《扫二维码-添加 陈经理 微信-咨询内衬四氟滑杆式旋转阀》

　　Quick release sliding rod rotary valve lined with PTFE core function:

　　1. Ultimate corrosion resistance isolation: PTFE can withstand almost all strong acids (such as concentrated sulfuric acid, hydrofluoric acid, aqua regia), strong alkalis, and organic solvents, solving the problem of metal material corrosion and failure.

　　2. Anti metal contact: Copper and zinc are prohibited, and a physical barrier is formed after lining to block the contact between corrosive media of lithium battery raw materials/chemical materials and metal valve bodies/cores.

　　3. Excellent sealing and anti sticking: With extremely low surface tension and non stick properties, it prevents medium crystallization or wall blockage of the flow channel; Combined with elastic deformation ability, it can achieve a tight fit and meet the zero leakage standard (ANSI Class VI), especially suitable for frequent opening and closing scenarios.

　　4. Friction reducing lubrication and torque reduction: PTFE has an extremely low coefficient of dynamic and static friction, significantly reducing the frictional resistance between rotating parts and valve seats, lowering operating torque, preventing jamming, and extending mechanical life.

　　5. Wide temperature adaptability: It can work stably within the range of -196 ℃ to+200 ℃ (some processes can reach 250 ℃), meeting the extreme temperature requirements of most chemical industries while maintaining chemical stability. ‌‌

　　6. Quick cleaning and maintenance: for material bonding, quick disassembly and cleaning, quick reset. Adopting a sliding rod locking mechanism, the valve body can be quickly opened by hand or with simple operation. The rotor is easy to disassemble, easy to clean, and has no hygiene dead corners, meeting the requirements of food and pharmaceutical GMP.

　　Changzhou Tongdeli/Jiangsu Tongdeli specializes in the production of (B) GFY and YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high-temperature and high-pressure rotary valves, high-temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE nylon polyurethane, arch breakers, silo scraper crushers, dispersing and crushing valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　Partial customer requirements:

　　In the lithium battery industry, the rotary valve housing is made of 304. lined with PTFE, the rotor is made of PTFE, the main shaft is made of 2205 duplex stainless steel, and the single-sided gap between the rotor and the valve body is 0.25. The main shaft seal is gas sealed (packing+oil seal+air distribution ring), the rotary valve volume is 4L, the speed is 25 revolutions per minute, the motor is Wannana frequency converter, and the reducer is from Guomao.

　　Lithium battery raw material transportation, Q ≥ 1t/h (material bulk density 0.6g/cm ³), DN200 rotary valve (closed fan) SUS304 lined with PTFE, variable frequency motor protection level IP55. variable frequency drive speed (power 1.1kW, current 2.67A, cooling fan power 42W, current 0.1A).

　　Lined PTFE star shaped unloader, material: crystalline glucose, temperature 70-80 ℃, processing capacity 10T/H. Moisture content 10%, bulk density 650g/L. Self weight cutting requires upper circle and lower part, lined with 304 PTFE. The total height of the air damper for the unloader is 580mm, with a body height of 500mm and a mirror height of 80mm. It is designed with a round sky and square shape. The upper flange has 4 screw holes with a diameter of 12mm and a center to center distance of 305mm. The lower base has 4 screw holes with a diameter of 14mm and a center to center distance of 250mm on the same side and 310mm on the left and right sides. It is equipped with a reducer with hard bevel teeth and a Shilin motor.

　　Used in the energy storage industry, the material is wet material after pressure filtration, in the form of flakes, with a water content of 10%, and the material is very soft. The DN250 pipeline discharge valve is made of 304 material lined with polytetrafluoroethylene PTFE, and the rotor is also made of PTFE. The motor is directly driven, and the discharge valve shaft seal adopts polytetrafluoroethylene packing, and the shaft seal adopts packing and airtight seal.

　　Material: Pharmaceutical powder, at room temperature, material 304 lined with PTFE, inlet and outlet DN200. 12 liters/revolution, impeller: open type 6-piece cast U-shaped, external bearing, shaft end seal: PTFE packing, reducer motor: cycloidal BI-35-1.1kw (explosion-proof).

　　PTFE rotary valve+arch breaking valve. A rotary valve lined with PTFE is required to be DN100. made of stainless steel lined with PTFE, with a solid feeding speed of 1kg/min. The valve body is equipped with a DN25 nitrogen blowing nozzle. Transport materials containing bromine elements. Corresponding arch breakers are provided to prevent the formation of arch bridges due to material failure, and the arch is also lined with PTFE.

　　Star shaped discharge valve lined with PTFE, DN50 national standard flange for feed inlet, explosion-proof motor, 1.5kw, solid material conveying capacity of 1m3/hr, material: phosphorus pentasulfide, corrosive, installed below the reaction vessel, which needs to be evacuated. Good sealing, material 316L or PTFE lining is better.

　　Material: Chemical plant disinfectant powder, previously made of stainless steel with corrosion resistance, requires high corrosion resistance, temperature of 70-80 degrees, size DN300. self weight cutting, reducer SEW-EURODRIVE, NORD, motor Wolong, ABB， Siemens
