风送式旋转卸料阀压力范围：2kg/cm²系统压力或压差。

　　增大入口/出口：正方形，没有截面尺寸对料流的限 制从而可达高产量。

　　普通型：结构紧凑，占用空间小。

　　轴承外置式：有效的防止粉尘侵入轴承，增大设备适应较高温度的使用范围。

　　驱动方式：链驱动/马达直联驱动。

　　动力配置：摆线针轮减速机、Y系列电机(可按客户指定动力配置)。

　　材质选项：钛合金、铝合金、陶瓷、不锈钢、碳钢等。

　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粉料、超微粉体等。

　　Pressure range of pneumatic rotary discharge valve: 2kg/cm ² System pressure or differential pressure.

　　Increase the inlet/outlet: square, with no restrictions on material flow due to cross-sectional size, achieving high production.

　　Normal type: compact structure, occupying small space.

　　External bearing type: effectively prevents dust from entering the bearing, increasing the equipment's adaptability to higher temperature usage range.

　　Drive mode: chain drive/motor direct drive.

　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).

　　Material options: titanium alloy, aluminum alloy, ceramic, stainless steel, carbon steel, etc.

　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production, and customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valve can handle various types of particles, flakes, blocks, powders, and ultrafine powders in industries such as lithium batteries, steel mills, power plants, cement, mines, environmental protection, plastics, chemicals, food, and pharmaceuticals.
