【风送滑杆式卸料阀】

主要结构：外壳金属;物料接触部分：内衬陶瓷(也可碳化钨、尼龙、四氟、特氟龙、聚氨酯、合金、不锈钢等)。

主要用于化工、食品、药材、锂电原料输送。

针对物料粘接，风力直吹转子清理。快拆清理，快速复位。

清洗前的拆卸。松开螺栓手柄，沿导柱将端盖轻轻拉至极限，抽出叶轮，双手握住叶轮两端抽颈取出。清洗后，装入叶轮(转动叶轮使花键齿合)，推入端盖(转动活动轴柄使花键齿合)，拧紧螺栓手柄。【电话/微信咨询：陈经理18068546632】

轴承外置式：有效的防止粉尘侵入轴承，增大设备适应较高温度的使用范围。

驱动方式：链驱动/马达直连驱动口。

动力配置：摆线针轮减速机、Y系列电机(可按需方指定动力配置)。

主要材料：不锈钢304-316、四氟、尼龙、钛合金、铝合金、各种合金等。【电话/微信咨询：陈经理 18068546632】

我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开阀、清洁阀、风送式旋转阀等产品。广泛应用于锂电池、粮食、饲料、石油化工、制药、淀粉、油脂、化工干燥、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。

       《扫二维码-添加 陈经理 微信-咨询风送滑杆式卸料阀》

Wind driven sliding rod unloading valve

Main structure: metal shell; Material contact part: lined with ceramic (also tungsten carbide, nylon, PTFE, PTFE, polyurethane, alloy, stainless steel, etc.).

For material bonding, clean the rotor with direct wind blowing. Quick disassembly and cleaning, quick reset.

Disassemble before cleaning. Release the bolt handle, gently pull the end cover along the guide column to the limit, extract the impeller, and hold both ends of the impeller with both hands to remove the neck. After cleaning, install the impeller (rotate the impeller to engage the spline teeth), push in the end cover (rotate the movable shaft handle to engage the spline teeth), and tighten the bolt handle.

External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.

Drive mode: chain drive/motor directly connected to the drive port.

Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).

Main materials: stainless steel 304-316. PTFE, nylon, titanium alloy, aluminum alloy, various alloys, etc.
