关风机入口/出口：入口为圆口并配有透明视窗，以便观察物料的流动状况;出口为方形增大了出口面积使物料顺利排出。

　　普通型：结构紧凑，占用空间小。

　　轴承外置式：防止粉尘侵入轴承、增大适应温度的范围。

　　轴承外置式安装、性能优异。

　　驱动方式：马达直联驱动为主、链驱动。

　　关风机材质：碳钢、铸铁、不锈钢、陶瓷、尼龙、四氟、特氟龙、钛合金、铝合金、各种合金系列等。【电话/微信咨询：陈经理18068546632】

　　关风机的安装：

　　1、检查产品经过运输或贮藏后是否损坏锈蚀;叶轮应能灵活转动。

　　2、与关风器的结合平面应平整，平面度不大于0.5mm，以免机壳变形引起故障。

　　3、关风器安装后要校正水平，紧固固定螺栓，叶轮能灵活转动无障碍。【电话/微信咨询：陈经理18068546632】

　　我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开阀、清洁阀、风送式旋转阀等产品。广泛应用于锂电池、粮食、饲料、石油化工、制药、淀粉、油脂、化工干燥、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。

           《扫二维码-添加 陈经理 微信-咨询风送式关风机》

　　Shut down the inlet/outlet of the fan: The inlet is circular and equipped with a transparent window for observing the flow of materials; The square shape of the outlet increases the outlet area and facilitates the smooth discharge of materials.

　　Ordinary type: compact structure and small space occupation.

　　External bearing: prevents dust from entering the bearing and increases the temperature adaptability range.

　　External installation of bearings, excellent performance.

　　Drive mode: mainly direct motor drive, chain drive.

　　Material of the fan: carbon steel, cast iron, stainless steel, ceramic, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, various alloy series, etc.

　　Installation of shutdown fan:

　　1. Check whether the product is damaged or corroded after transportation or storage; The impeller should be able to rotate flexibly.

　　2. The joint plane with the air conditioner should be flat, with a flatness of no more than 0.5mm, to prevent deformation of the casing and potential malfunctions.

　　3. After the installation of the air conditioner, it is necessary to calibrate the level, tighten the fixing bolts, and ensure that the impeller can rotate flexibly without obstacles.
