　　锂电行业专用打散破碎阀，整体材质：316L不锈钢，密封：气密封，口径：DN200.外部喷砂，内部镜面处理，型号：BPS-F-DN200.锂电负极材料结块打散，冷却釜出口破碎机：阀体：316L，破碎桨叶：316L，外表面：喷砂处理，规格：DN200-PN16(PL)，法兰标准：HG/T20592-2009(B)，国茂齿轮减速机，皖南工频电机1.5KW，二级能效，IP55.轴端气密封配B52调压阀，直连传动。　　打散破碎阀工作原理：　　动力传递‌：电机经减速机将高速低扭转为低速高扭，驱动破碎主轴或双轴组定向/反向同步旋转。　　破碎作用‌：物料进入阀体后，被高速运动的破碎齿/刀片/爪组通过剪切、挤压、撕扯等方式分解块料，直至打散破碎到客户需求粒度，破碎齿多种形式，或可定制;单轴/双轴/多叶交错式，款式齐全。　　协同控制‌：部分型号集成启闭调节功能，在破碎同时实现定量连续卸料，防止料仓搭桥、起拱、卡料。　　安全保护‌：遇不可碎硬物时，可触发过载反转或停机，避免损坏。　　刀片蕞佳的材质选择包括高碳钢、合金钢、高速钢和硬质合金。这些材质各有其独特的优点，适用于不同的工作条件和需求。　　部分客户需求：　　破碎阀DN500. PN6.介质：锂辉石酸化熟料，破碎前≤30mm,破碎到≤8mm;含水率≤6%,物料堆密度890g/m³;介质流量37t/h;工作温度300℃。　　管道式破碎机采购技术要求：1、型号 ZXQ-F-DN200-DN200(气密封);2、两端盖密封形式采用气密封，配减压阀;3、与物料接触部位喷涂碳化钨，厚度≥0.2mm;4、减速机型号型号:KAF47-10.56-2.2KW-M1-A;5、电机型号：YE4-100L1-4 功率：2.2kw 电压：380V;6、接口法兰 DN200 PN10;7、整机材质：304 不锈钢;8、铜锌含量：≤1%。　　物料：锂电池碳酸锂:4.5t/h，堆密度370kg/cm2.D90=13um。形式:对齿破碎机;规格:DN300;接触物料材质:S30408;框架:碳钢刷漆;设计温度:-15~60°C;设计压力:-2~3kPag;表面要求:内表面抛光Ra0.4.外表面Sa2;破碎粒径:碎前2-5cm，碎后8mm;设计产能:4.5t/h。　　锂电破碎阀 正极块料破碎阀 负极块料破碎器 石墨电动破碎阀  镍包石墨破碎阀  锂电极片涂覆及隔膜涂层材料打散破碎阀  氮化硼打散阀 电解锰片打散卸料阀 锂电池碳酸锂电动破碎阀　　电动破碎阀 破碎阀 卸料器破碎阀 管道破碎机 可拆卸破碎阀、清洗型破碎阀、拉杆式破碎打散阀、不锈钢破碎打散阀、碳化钨破碎旋转阀、锂电打散卸料器　　我公司同得利专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。 《扫二维码-添加 陈经理 微信-咨询锂电行业专用打散破碎阀》　　Lithium battery industry specific breaking valve, overall material: 316L stainless steel, seal: airtight seal, diameter: DN200. external sandblasting, internal mirror treatment, model: BPS-F-DN200. Lithium battery negative electrode material clumping and breaking, cooling kettle outlet crusher: valve body: 316L, crushing blade: 316L, outer surface: sandblasting treatment, specification: DN200-PN16 (PL), flange standard: HG/T20592-2009 (B), Guomao gear reducer, Wannan power frequency motor 1.5KW, secondary energy efficiency, IP55. Shaft end gas seal with B52 pressure regulating valve, directly connected transmission.　　Working principle of dispersing and crushing valve:　　Power transmission: The motor converts high-speed low torque into low-speed high torque through a reducer, driving the crushing spindle or dual axis group to rotate synchronously in a directional/reverse direction.　　Crushing effect: After the material enters the valve body, it is broken down into blocks by high-speed moving crushing teeth/blades/claws through cutting, squeezing, tearing, and other methods until it is dispersed and crushed to the customer's required particle size. The crushing teeth come in various forms or can be customized; Single axis/dual axis/multi blade staggered design, with a complete range of styles.　　Collaborative control: Some models integrate opening and closing adjustment functions to achieve quantitative continuous unloading while crushing, preventing silo bridging, arching, and jamming.　　Safety protection: When encountering unbreakable hard objects, it can trigger overload reversal or shutdown to avoid damage.　　The best material choices for blades include high carbon steel, alloy steel, high-speed steel, and hard alloy. These materials each have their unique advantages and are suitable for different working conditions and needs.　　Partial customer requirements:　　Crushing valve DN500. PN6. medium: spodumene acid clinker, ≤ 30mm before crushing, ≤ 8mm after crushing; moisture content ≤ 6%, material bulk density 890g/m ³; Medium flow rate 37t/h; The working temperature is 300 ℃.　　Technical requirements for procurement of pipeline crusher: 1. Model ZXQ-F-DN200-DN200 (airtight seal); 2. The sealing form of the two end covers adopts gas sealing and is equipped with a pressure reducing valve; 3. Spray tungsten carbide on the contact area with the material, with a thickness of ≥ 0.2mm; 4. Gearbox model: KAF47-10.56-2.2KW-M1-A; 5. Motor model: YE4-100L1-4 Power: 2.2kw Voltage: 380V; 6. Interface flange DN200 PN10; 7. Material of the whole machine: 304 stainless steel; 8. Copper and zinc content: ≤ 1%.　　Material: Lithium battery Lithium carbonate: 4.5t/h, bulk density 370kg/cm2. D90=13um. Form: Tooth crusher; Specification: DN300; Contact material material: S30408; Framework: Carbon steel painted; Design temperature: -15~60 ° C; Design pressure: -2~3kPag; Surface requirements: inner surface polished Ra0.4. outer surface Sa2; Crushed particle size: 2-5cm before crushing, 8mm after crushing; design capacity: 4.5t/h.　　Lithium ion crushing valve, positive electrode block material crushing valve, negative electrode block material crusher, graphite electric crushing valve, nickel coated graphite crushing valve, lithium electrode sheet coating and diaphragm coating material dispersing crushing valve, boron nitride dispersing valve, electrolytic manganese sheet dispersing discharge valve, lithium battery, lithium carbonate electric crushing valve　　Electric crushing valve, crushing valve, unloading device, crushing valve, pipeline crusher, detachable crushing valve, cleaning type crushing valve, pull rod crushing and dispersing valve, stainless steel crushing and dispersing valve, tungsten carbide crushing rotary valve, lithium battery crushing and unloading device　　Our company specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high temperature and high pressure rotary valves, high temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE nylon polyurethane, arch breaking machines, silo scraper crushers, fragmentation valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　两端出料螺旋输送机是一种‌单点进料、双向分流‌的专用输送设备，核心作用是将中间投入的物料通过‌反向螺旋叶片‌同时向机头、机尾两个方向推送，实现‌一机两向分流供料‌或‌均衡配给‌。‌‌　　The two end discharge screw conveyor is a specialized conveying equipment with single point feeding and bidirectional diversion. Its core function is to push the materials put in the middle towards the head and tail of the machine simultaneously through reverse spiral blades, achieving one machine two-way diversion feeding or balanced distribution. ‌‌　　两端出料螺旋输送机常见采用双轴螺旋旋转产生轴向推力‌，配合‌机壳内多点卸料口与闸门控制‌，实现物料从中间进料、向‌两端同时或选择性排出‌的连续推移输送。　　Two end discharge screw conveyors commonly use dual axis spiral rotation to generate axial thrust, combined with multi-point discharge ports and gate control inside the casing, to achieve continuous pushing and conveying of materials from the middle to both ends simultaneously or selectively.　　两端出料螺旋输送机核心工作原理：　　‌动力驱动‌：电机经减速机带动螺旋轴(有轴或无轴)旋转，螺旋叶片对物料施加法向推力。　　‌轴向移动‌：物料受重力及机壳壁摩擦阻力约束，不随叶片旋转，仅在叶片轴向分力作用下沿槽底向前滑移(类似螺母沿螺杆运动)。　　‌双向分流‌：进料口通常位于机槽中部或特定位置，物料被旋转叶片同时推向左右两侧;两端出料口设有‌调节闸门或挡板‌，通过开闭控制单端出料、双端同时出料或比例分配 。　　‌连续推移‌：后续物料持续推动前方物料形成“推挤流”，直至从选定出料口排出 。‌‌　　两端出料螺旋输送机关键结构及材质：　　结构组成：主轴、螺旋叶片、料槽、机盖、驱动装置等。　　特点：中间进料，两端出料。结构紧凑，占用空间小;出口配有透明视窗，以便观察物料的流动状况。　　行业应用：锂电新能源、制药、化工、食品、环保行业、钢厂等。　　材质：Q235、304、310S、316L、TC4等。　　处理：镜面、碳化钨、特氟龙、陶瓷粉、衬四氟等。　　两端出料螺旋输送机适用场景：　　‌适用物料‌：粉状、颗粒状及小块状散料，温度 -20℃~250℃，不宜输送粘性大、易结块或易变质物料 。　　应用行业：锂电池、化工、医药、食品、塑胶、环保、水泥、矿山、电厂、钢厂等。　　‌优势‌：密封性好、可多点装卸、结构紧凑、支持双向灵活卸料。　　‌注意‌：反向输送或长期单侧满载可能影响轴承寿命，需按设计工况操作 。‌‌　　常州同得利机械厂拥有多年的研发生产/定制螺旋输送机，卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的螺旋输送机/旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。　　部分客户需求：　　储罐粉料通过利用螺旋输送机输送，把粉料输送到A罐子，当A罐子满了，再把料输送到B罐子，物料是生物质粉，8t/h的输送量，堆密度在400左右，粒径在1mm，DN300.接触物料部分2205双向钢材质或者哈氏合金。　　物料：三水合氟化铝AlF3·3H2O，氢氧化铝，密度1.0t/m³，双向给料螺栓输送机(一个入口， 两个出口)，主要是把物料输送到两边罐子。尺寸DN300.每端距离2米，材质不锈钢304.　　物料化肥，DN500.304材质。与物料接触部分为06Cr19Ni10不锈钢，其它部分碳钢，把化肥输送到两端分流罐子，中间进料。　　物料：不到1mm化工产品有腐蚀性，料仓下料易结块堵塞，严重影响称重计量包装，需要加装破碎卸料阀，DN300接口，316L材质，破碎阀下面接双向螺旋给料机，两端出料到各自对应的储罐。　　Core working principle of two end discharge screw conveyor:　　Power drive: The motor drives the spiral shaft (with or without shaft) to rotate through the reducer, and the spiral blades apply normal thrust to the material.　　Axial movement: The material is constrained by gravity and frictional resistance of the casing wall, and does not rotate with the blades. It only slides forward along the groove bottom under the axial force of the blades (similar to a nut moving along a screw).　　Bidirectional diversion: The feed inlet is usually located in the middle of the machine slot or at a specific position, and the material is pushed to the left and right sides simultaneously by the rotating blades; Both ends of the discharge port are equipped with adjustable gates or baffles, which control the discharge of single end, simultaneous discharge of both ends, or proportional distribution through opening and closing.　　Continuous pushing: The subsequent material continues to push the material ahead to form a "pushing flow" until it is discharged from the selected discharge port. ‌‌　　Key structures and materials of the two end discharge screw conveyor:　　Structural composition: spindle, spiral blades, material trough, machine cover, driving device, etc.　　Features: Feed in the middle and discharge at both ends. Compact structure and small space occupation; The exit is equipped with a transparent window for observing the flow of materials.　　Industry applications: lithium battery new energy, pharmaceutical, chemical, food, environmental protection industries, steel mills, etc.　　Materials: Q235. 304. 310S, 316L, TC4. etc.　　Processing: mirror, tungsten carbide, PTFE, ceramic powder, PTFE lining, etc.　　Applicable scenarios for two end discharge screw conveyor:　　Applicable materials: Powder, granular, and small block shaped bulk materials, temperature -20 ℃~250 ℃, not suitable for conveying materials with high viscosity, easy agglomeration, or easy deterioration.　　Application industries: lithium batteries, chemicals, pharmaceuticals, food, plastics, environmental protection, cement, mining, power plants, steel mills, etc.　　Advantages: Good sealing, multi-point loading and unloading, compact structure, and support for bi-directional flexible unloading.　　Attention: Reverse conveying or long-term one-sided full load may affect the bearing life, and should be operated according to the design conditions. ‌‌　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production/customization of screw conveyors and discharge valve rotary valves, adhering to the principle of quality first and customer first. Our spiral conveyor/rotary valve is capable of handling various types of particles, flakes, blocks, adhesives, powders, ultrafine powders, etc. in industries such as lithium batteries, steel mills, power plants, cement, mining, environmental protection, plastics, chemical, food, and pharmaceuticals.　　Partial customer requirements:　　The storage tank powder is transported by a screw conveyor to tank A. When tank A is full, the material is then transported to tank B. The material is biomass powder with a conveying capacity of 8t/h, a bulk density of around 400. a particle size of 1mm, DN300. and a contact material of 2205 bidirectional steel or Hastelloy alloy.　　Material: AlF3 · 3H2O trihydrate aluminum fluoride, aluminum hydroxide, density 1.0t/m ³, bidirectional feeding bolt conveyor (one inlet, two outlets), mainly used to transport materials to the two tanks. Size DN300. distance of 2 meters from each end, made of stainless steel 304.　　Material fertilizers, DN500. 304 material. The part in contact with the material is made of 06Cr19Ni10 stainless steel, while the other part is made of carbon steel. The fertilizer is transported to the two ends of the diversion tank and fed into the middle.　　Material: Chemical products with a diameter of less than 1mm are corrosive, and the material stored in the silo is prone to clumping and blockage, which seriously affects weighing and measuring packaging. It is necessary to install a crushing discharge valve with a DN300 interface and 316L material. The crushing valve should be connected to a two-way spiral feeder under it, and the two ends should be discharged to their corresponding storage tanks.

　　锁气阀/电动锁气器是气力输送系统中的关键设备，也是除尘和加料系统的常用设备。根据物料的特性、用途和使用条件的不同，电动锁气器有多种结构形式。电动锁气器的选型要依据被输送物料的特性如粒度大小、黏附性、温度、湿度来决定的。【电话/微信咨询：陈经理18068546632】　　锁气阀/电动锁气器用途：　　电动锁气器适用于火力发电厂粉煤灰、煤粉、石膏粉等物料中近距离(300米内)气力输送系统。也可用于水泥、冶金、化工等其他行业中粉状物料的低压气力输送系统。　　常州同得利机械厂主要制造适用于粘性的，含坚硬杂质的以及高温高压或高真空情况下使用的电动锁气器。以及小尺寸的电动锁气器，都是非常规结构非标定制。【电话/微信咨询：陈经理18068546632】       《扫二维码-添加 陈经理 微信-咨询锁气阀/电动锁气器》　　Lock valve/electric lock valve is a key equipment in pneumatic conveying system and a commonly used equipment in dust removal and feeding system. According to the characteristics, uses, and usage conditions of materials, electric air locks have various structural forms. The selection of electric air locks should be based on the characteristics of the conveyed material, such as particle size, adhesion, temperature, and humidity.　　Application of air lock valve/electric air lock:　　Electric air locks are suitable for close range (within 300 meters) pneumatic conveying systems for materials such as fly ash, coal powder, gypsum powder, etc. in thermal power plants. It can also be used in low-pressure pneumatic conveying systems for powdered materials in other industries such as cement, metallurgy, and chemical engineering.　　Changzhou Tongdeli Machinery Factory mainly manufactures electric air locks suitable for use in viscous, hard impurity containing, high-temperature, high-pressure, or high vacuum situations. And small-sized electric air locks are all customized with unconventional structures and non-standard specifications.

　　风送式旋转阀/卸料阀压力范围：2kg/cm²系统压力或压差。　　增大入口/出口：正方形，没有截面尺寸对料流的限 制从而可达高产量。　　轴承外置式：有效的防止粉尘侵入轴承，增大设备适应较高温度的使用范围。　　驱动方式：链驱动/马达直连驱动口。　　正压稀相气力输送系统是采用罗茨风机或者罗茨空压泵作为动力源。利用空气动能作为输送介质，物料以比较高的速度并以分散悬浮的状态在管道中输送。输送的压力一般根据工况条件不同可在几千帕到几百千帕范围内调整。　　正压密相输送系统采用压缩空气作动力源传输物料。采用强制性气力输送，依靠密闭压力容器(发送罐)作发送器，一般气源压力为0.5 Mpa～0.7Mpa，运行压力0.3～0.5Mpa，发送罐只能采取间隙性输送方式，输送路程可达1000m以上。物料在管道内以较低速度、沙丘状态、流态化或团聚状态输送的方式称为正压密相输送。【电话/微信咨询：陈经理18068546632】    《扫二维码-添加 陈经理 微信-咨询不锈钢气力输送旋转阀》　　Pressure range of pneumatic rotary valve/discharge valve: 2kg/cm ² system pressure or pressure difference.　　Increase inlet/outlet: Square, without cross-sectional size restrictions on material flow, thus achieving high yield.　　External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.　　Drive mode: chain drive/motor directly connected to the drive port.

　　偏置式旋转阀适用于≤2kg/cm²系统压力或压差。　　设置排气口(正压输送时选用)将叶轮旋转带出的气体通过排气口送至排气装置，提高填充效率。　　防切料入口设计，即便上游充满物料也可安全启动。偏置式进出料口设计：减少了物料的破碎与损坏。　　偏置式旋转阀主要用于钢厂、电厂、水泥、矿山原料输送。【电话/微信咨询：陈经理18068546632】        《扫二维码-添加 陈经理 微信-咨询链驱动偏置式旋转阀》　　Biased rotary valves are suitable for system pressures or pressure differentials of ≤ 2kg/cm ².　　Set up an exhaust port (selected for positive pressure conveying) to send the gas carried out by the impeller rotation to the exhaust device through the exhaust port, improving the filling efficiency.　　Anti cutting material inlet design ensures safe start-up even when the upstream is filled with materials. Offset inlet and outlet design: reduces material breakage and damage.　　Offset rotary valves are mainly used for conveying raw materials in steel mills, power plants, cement, and mines.

电动破碎阀：箱体上的顶端设有进料口，箱体的侧壁开设有出料口，箱体中设有主动转子和从动转子，主动转子上和从动转子上均设有转动破碎板，主动转子和从动转子平行设置，在主动转子的左端设有驱动主动转子转动的驱动电机，主动转子的右端设有主动齿轮，从动转子的右端设置有与主动齿轮啮合的从动齿轮，通过设置相对转动的主动转子和从动转子且在主动转子和从动转子上设置破碎板的方式进行碎料。电动破碎阀 水泥块料破碎机 可拆卸破碎阀、物料破碎阀、粉煤灰破碎打散阀、电石渣破碎打散阀 【电话/微信咨询：陈经理18068546632】破碎物料：沫煤、锂矿、结块颗粒、磷酸铁粉、电石渣烧生石灰、碳酸钙、锂电池正极材料碳纳米管材料、硬脂酸盐产品、净化灰块状物料、炭黑结块            《扫二维码-添加 陈经理 微信-咨询电动破碎阀》Electric crushing valve cement block crusher detachable crushing valve, material crushing valve, fly ash crushing and dispersing valve, carbide slag crushing and dispersing valveCrushed materials: foam coal, lithium ore, agglomerated particles, iron phosphate powder, calcined quicklime from carbide slag, calcium carbonate, positive electrode materials for lithium batteries, carbon nanotube materials, stearate products, purified ash block materials, carbon black agglomerates

       DN200陶瓷卸料阀-国盛卸料阀类型：滑杆式/侧快拆/耐高压/耐高温/锁风式/风送滑杆式/防卡型卸料阀(总有一款适合您的需求)陶瓷卸料阀主要结构：外壳金属;物料接触部分：内衬陶瓷(也可尼龙、四氟、特氟龙、聚氨酯等)。陶瓷卸料阀主要用于输送锂电池正极材料，负极材料，磷酸铁锂，三元材料等物料的输送和卸料，可以提高生产效率，保证物料的质量的和稳定性，同时满足环保和安全的要求。陶瓷卸料阀特点：耐高温、耐磨、使用寿命长。陶瓷卸料阀技术研发于2015年，批量生产于2017年，2020年更新第3代陶瓷星型旋转阀，目前有陶瓷星型旋转阀专 利。【电话/微信咨询：陈经理18068546632】锂电/化工卸料阀-陶瓷卸料阀由本公司自主研制，已取得多项国家专 利。本品适用于不可接触金属物料，多用于锂电正极原料的生产制作。陶瓷阀的优点是超强耐磨，而且不会对锂电材料造成污染，是新能源大开发进程中一大助力。         《扫二维码-添加 陈经理 微信-咨询陶瓷卸料阀》DN200 Ceramic Unloading Valve - Guosheng Unloading Valve Types: Sliding Rod/Side Quick Release/High Pressure/High Temperature/Lock Air/Air Delivery Sliding Rod/Anti jamming Unloading Valve (There is always one that suits your needs)The main structure of ceramic discharge valve: metal shell; Material contact part: lined with ceramic (also nylon, PTFE, PTFE, polyurethane, etc.).Ceramic discharge valves are mainly used for conveying and discharging materials such as positive electrode materials, negative electrode materials, lithium iron phosphate, ternary materials, etc. of lithium batteries. They can improve production efficiency, ensure the quality and stability of materials, and meet environmental and safety requirements.

       DN200内衬陶瓷旋转阀-防尘帽-防异物。本产品由本公司自主研制，已取得多项国家专 利。本品适用于不可接触金属物料，多用于锂电正极原料的生产制作。陶瓷阀的优点是超强耐磨，而且不会对锂电材料造成污染，是新能源大开发进程中一大助力。DN200 lined ceramic rotary valve - dust cap - anti foreign object. This product is independently developed by our company and has obtained multiple national patents. This product is suitable for non-contact metal materials and is mainly used in the production and manufacturing of lithium positive electrode materials. The advantages of ceramic valves are super strong wear resistance and no pollution to lithium battery materials, which is a major boost in the process of new energy development.陶瓷旋转阀主要结构：外壳金属;物料接触部分：内衬陶瓷(也可尼龙、四氟、特氟龙等)。内衬陶瓷旋转阀主要用于输送锂电池正极材料、磷酸铁锂、三元材料等。内衬陶瓷旋转阀特点：耐高温、耐磨、使用寿命长。【电话/微信咨询：陈经理18068546632】技术研发于2015年，批量生产于2017年，2020年更新第3代陶瓷星型旋转阀，目前有陶瓷星型旋转阀专 利。            《扫二维码-添加 陈经理 微信-咨询陶瓷星型阀》The main structure of ceramic rotary valve: metal shell; Material contact part: lined with ceramic (also nylon, PTFE, PTFE, etc.).The lined ceramic rotary valve is mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, etc.Features of lined ceramic rotary valve: high temperature resistance, wear resistance, and long service life.The technology was developed in 2015. mass-produced in 2017. and the third-generation ceramic star shaped rotary valve was updated in 2020. Currently, there is a patent for ceramic star shaped rotary valve.

旋转阀/卸料阀的工作原理主要涉及电动机驱动减速机，通过联轴器或链轮使旋转阀的转子旋转。在旋转过程中，材料位于旋转叶片的空间内，叶片的旋转将材料带到排出口，材料的自重使其流入输送系统或储藏室。这种工作方式使得卸料阀能够均匀、连续地向输料管供料，保证气力输出管内的气体和固体物质保持稳定，从而确保气力输送系统的正常工作。同时，卸料阀还具有锁气作用，能够隔断卸料阀上下部的气压。‌【电话/微信咨询：陈经理18068546632】内衬四氟旋转阀基本介绍：四氟是一种化学性稳定、具有优异的耐高温、耐低温和不粘附性的高分子材料，可以在极端的化学环境下使用。四氟内衬是在金属、陶瓷等材料表面制成的一种覆盖层，主要用于防腐、防粘附和减少摩擦。内衬四氟旋转阀作用：耐高温性：四氟旋转阀卸料阀具有出色的耐高温性能，能够在高温环境下保持稳定的工作状态。它适用于化工反应过程中产生的高温介质的控制和调节，确保旋转阀的密封性和流体的稳定输送。【电话/微信咨询：陈经理18068546632】防粘附作用：四氟旋转阀表面具有良好的不粘附性，能够防止设备表面附着物的黏附，避免管道物料：粉体/颗粒料在长期运行过程中出现结垢、石灰积垢等现象，从而提高了设备的效率。            《扫二维码-添加 陈经理 微信-咨询产品》The working principle of a rotary valve/discharge valve mainly involves an electric motor driving a reducer, which rotates the rotor of the rotary valve through a coupling or sprocket. During the rotation process, the material is located in the space of the rotating blades, and the rotation of the blades brings the material to the discharge outlet. The self weight of the material causes it to flow into the conveying system or storage room. This working method enables the discharge valve to uniformly and continuously feed the conveying pipe, ensuring that the gas and solid substances in the pneumatic output pipe remain stable, thereby ensuring the normal operation of the pneumatic conveying system. At the same time, the discharge valve also has a locking effect, which can block the air pressure at the upper and lower parts of the discharge valve. ‌Introduction to PTFE lined rotary valve:Tetrafluoroethylene is a chemically stable polymer material with excellent resistance to high and low temperatures and non adhesiveness, which can be used in extreme chemical environments. PTFE lining is a covering layer made on the surface of metal, ceramic and other materials, mainly used for corrosion prevention, anti adhesion and reducing friction.Function of PTFE lined rotary valve:High temperature resistance: The PTFE rotary valve discharge valve has excellent high temperature resistance and can maintain a stable working state in high temperature environments. It is suitable for controlling and regulating high-temperature media generated in chemical reaction processes, ensuring the sealing of rotary valves and stable fluid transport.Anti adhesion effect: The surface of the PTFE rotary valve has good non adhesion, which can prevent the adhesion of surface attachments and avoid scaling and lime accumulation of pipeline materials such as powder/particle materials during long-term operation, thereby improving the efficiency of the equipment.
