旋转阀/卸料阀的工作原理主要涉及电动机驱动减速机，通过联轴器或链轮使旋转阀的转子旋转。在旋转过程中，材料位于旋转叶片的空间内，叶片的旋转将材料带到排出口，材料的自重使其流入输送系统或储藏室。这种工作方式使得卸料阀能够均匀、连续地向输料管供料，保证气力输出管内的气体和固体物质保持稳定，从而确保气力输送系统的正常工作。同时，卸料阀还具有锁气作用，能够隔断卸料阀上下部的气压。‌【电话/微信咨询：陈经理18068546632】

内衬四氟旋转阀基本介绍：

四氟是一种化学性稳定、具有优异的耐高温、耐低温和不粘附性的高分子材料，可以在极端的化学环境下使用。四氟内衬是在金属、陶瓷等材料表面制成的一种覆盖层，主要用于防腐、防粘附和减少摩擦。

内衬四氟旋转阀作用：

耐高温性：四氟旋转阀卸料阀具有出色的耐高温性能，能够在高温环境下保持稳定的工作状态。它适用于化工反应过程中产生的高温介质的控制和调节，确保旋转阀的密封性和流体的稳定输送。【电话/微信咨询：陈经理18068546632】

防粘附作用：四氟旋转阀表面具有良好的不粘附性，能够防止设备表面附着物的黏附，避免管道物料：粉体/颗粒料在长期运行过程中出现结垢、石灰积垢等现象，从而提高了设备的效率。

            《扫二维码-添加 陈经理 微信-咨询产品》

The working principle of a rotary valve/discharge valve mainly involves an electric motor driving a reducer, which rotates the rotor of the rotary valve through a coupling or sprocket. During the rotation process, the material is located in the space of the rotating blades, and the rotation of the blades brings the material to the discharge outlet. The self weight of the material causes it to flow into the conveying system or storage room. This working method enables the discharge valve to uniformly and continuously feed the conveying pipe, ensuring that the gas and solid substances in the pneumatic output pipe remain stable, thereby ensuring the normal operation of the pneumatic conveying system. At the same time, the discharge valve also has a locking effect, which can block the air pressure at the upper and lower parts of the discharge valve. ‌

Introduction to PTFE lined rotary valve:

Tetrafluoroethylene is a chemically stable polymer material with excellent resistance to high and low temperatures and non adhesiveness, which can be used in extreme chemical environments. PTFE lining is a covering layer made on the surface of metal, ceramic and other materials, mainly used for corrosion prevention, anti adhesion and reducing friction.

Function of PTFE lined rotary valve:

High temperature resistance: The PTFE rotary valve discharge valve has excellent high temperature resistance and can maintain a stable working state in high temperature environments. It is suitable for controlling and regulating high-temperature media generated in chemical reaction processes, ensuring the sealing of rotary valves and stable fluid transport.

Anti adhesion effect: The surface of the PTFE rotary valve has good non adhesion, which can prevent the adhesion of surface attachments and avoid scaling and lime accumulation of pipeline materials such as powder/particle materials during long-term operation, thereby improving the efficiency of the equipment.
